Avoid Air Energy Loss Raymond Mills Maintenance Easy
Avoid Air Energy Loss Raymond Mills Maintenance Easy Introduction:
Raymond mill is a kind of equipment used for high-fine powder processing of more than 280 kinds of materials in mining, chemical, construction and other industries.
Raymond mill is widely used in the fine powder processing of more than 280 kinds of materials in non-flammable and explosive industries such as barite, calcite, feldspar, talc, marble, limestone, dolomite, fluorite, lime, activated clay, activated carbon, bentonite, kaolin, cement, phosphate rock, gypsum, glass, thermal insulation materials, etc. with Mohs hardness not more than 9.3 and humidity below 6% in mining, chemical, construction and other industries. The finished particle size of R-type Raymond mill can be adjusted arbitrarily within the range of 80-325 mesh, and some materials can reach up to 600 mesh.
Avoid Air Energy Loss Raymond Mills Maintenance Easy Main Structure:
The structure of the machine is mainly composed of the main machine, analyzer, fan, finished product cyclone separator, micro powder cyclone separator and air duct. Among them, the main machine is composed of the frame, air inlet volute, scraper, grinding roller, grinding ring and cover.
Avoid Air Energy Loss Raymond Mills Maintenance Easy Technical Parameter:
Model |
Roller Number(pcs) |
Mill Roll Size (R*Hmm) |
Size and Height of Grinding Ring(mm) |
Maximum Feed Length(mm) |
Product Granularity (mm) |
Capacity(t/h) |
Motor Power(kw) |
3R1510 |
3 |
150*100 |
480*100 |
15 |
0.2-0.044 |
0.3-1 |
7.5 |
3R2615 |
3 |
260*150 |
780*150 |
20 |
0.2-0.044 |
1-1.5 |
18.5 |
3R2715 |
3 |
270*150 |
830*150 |
20 |
0.2-0.044 |
1-3 |
22 |
3R3016 |
3 |
300*160 |
880*160 |
20 |
0.2-0.044 |
1-4 |
30 |
3R3018 |
3 |
300*180 |
990*180 |
20 |
0.2-0.044 |
3-5 |
30 |
4R3216 |
4 |
320*160 |
1073*160 |
25 |
0.2-0.044 |
2-6 |
37 |
4R3220 |
4 |
320*200 |
1075*200 |
25 |
0.2-0.044 |
2-7 |
37 |
5R4119 |
5 |
410*190 |
1300*190 |
35 |
0.2-0.044 |
2-8.5 |
75 |
5R4121 |
5 |
410*210 |
1300*210 |
35 |
0.2-0.044 |
3-9 |
75 |
5R4125 |
5 |
410*250 |
1300*250 |
35 |
0.2-0.044 |
5-10 |
75 |
6R4528 |
6 |
450*280 |
1600*280 |
40 |
0.2-0.044 |
3-16 |
132 |
Raymond Mills Spare Parts
