Black Steel Tube Welding Machine Iron Tube Making Machine
- 150 Set / Sets per Month
- Shanghai port
- T/T L/C
- 3 days
- China Top Automatic Straight Seam Welding Carbon Steel Pipe Mill Production Line
- TG76 Square and Rectangular Pipe Mill Line
- Mild Steel Fast Roller Change Hollow Pipe Profile Mill Line
- Best Price Reliable Quality Steel Pipe Welding Machine Line
- High Frequency Welding Hollow Profile Steel Pipe Machine
- MS GI Pipe Making Machine China HF Precision Pipe Profile Making Line
Product Details
Brand Name: | TG | Place of Origin: | China | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Seaworthy packing
Product Description
Step1: Uncoiler
Uncoiler the function is to support and expand the strip, so strip can enter into machine to roll forming. Strip can be expanded by hydraulic or pneumatic and uncoiler can be rotated 180 degree. Strip expand speed can be adjusted, braking device designed with pneumatic or hydraulic cylinder to press the brake rubber block
Step2: Shear & end welding
It is used to shear the head and the end of the steel strip of two steel coils, cutting off the irregular part then welding two steel strips, so machine can work continuously.
Step3: Accumulator
Installed between shear & end welder and forming mill, horizontal spiral accumulator store a large amount of strip in a reasonable footprint space to give enough time for shear & end welder to cut and join the ends of two successive coils with non-stop tube mill
It has vertical cage type accumulator for small size tube mill
Step4: Forming
The function of this part is to make the steel strip become to the tube blank by forming rollers
Step5: welding & scarfing
The function of this part is to center the welding seam and guide the tube blank to welding device, so the welding seam will be closed before welding, use scarfing tool to remove the burr to ensure the smooth welding
Step6: Sizing
The function of this part is used to finish the tube blank from the forming machine, so the tube size can meet the physical dimension as customer required, form to square and rectangular and other shape profiles
Step7: Straightening
4 rolls turk head straightening, straighten pipe online to achieve the ideal flatness
Step8: Cut off saw
Cut off the pipe with required length, length of pipe can be set
With option of cold saw and flying saw
Step9: Run out table
This unit is to convey the finished pipe to packing, pipe transmit by dynamic roll. A signal sensing device installed in the end of run out table, when pipe touch the signal sensing device, it will feedback the signal to control panel, control panel start working and discharge the pipe
Company Profile
Taicang global machinery Co., Ltd, we professionally focus on the innovation, design, manufacturing and sale of metallurgical machines such as: tube mill line, slitting & cut to length line, roll forming machine as well as related materials
Based on our rich experience and know-how professional team in metallurgIcal equipment industry, we are dedicated to offer Integrity solution & Turkey project for our customers, include market analyze, machine designing and manufacturing, testing, shipping, installation and commission, training and after-sales service etc
Our mission is to provide highly qualified machines with competitive price, timely delivery, perfect machine commission and subsequent thoughtful/caring after-sale service
We have been establishing and keeping excellent business relationship with many valuable customers all over the world, mainly located in Southeast and South Asia, Middle East, Europe, Africa and South America… etc, We sincerely invite friends and all those who have interest in our machines and service to come China and visit our facilities.
