Higher Transmission Efficiency Grinding Mill Suitable For Non-explosive Materials
Efficiency Grinding Mill Suitable For Non-explosive Materials Introduction:
This Efficiency Grinding Mill Suitable For Non-explosive Materials is widely used in barite, calcite, carborundum, silicon carbide, potassium feldspar, marble, limestone, dolomite, fluorite, lime, titanium dioxide, activated carbon, bentonite, kaolin, white cement, calcium carbonate, gypsum, glass, manganese, titanium, refractory materials, insulation materials, coal gangue, carbon black, coal, clay, talc, shell, resin, ferric oxide, hong huang dan, quartz, petroleum coke with hardness less than 7 humidity, in more than 500 in charge of flammable and explosive materials powder processing under 6%, the product size can be adjusted in the range of 60-325 mesh, part of the material up to 1000 mesh.
Efficiency Grinding Mill Suitable For Non-explosive Materials Main Structure:
The structure of the machine mainly consists of a host, analyzer, fan, finished cyclone separator, micro powder cyclone separator, and air duct. Among them, the host is composed of a rack, an intake volute, a shovel, a grinding roller, a grinding ring, and a cover shell.
When working, the material that needs to be crushed is fed into the machine from the feeding hopper on the side of the hood. It relies on the grinding roller device suspended on the main engine's plum blossom frame to revolve around the vertical axis while rotating on its own. Due to the centrifugal force during rotation, the grinding roller swings outward and presses tightly against the grinding ring, causing the shovel to pick up the material and send it between the grinding roller and the grinding ring. The rolling and crushing of the grinding roller achieve the purpose of crushing the material.
Efficiency Grinding Mill Suitable For Non-explosive Materials Technical Parameter:
Model |
Roller Number(pcs) |
Mill Roll Size (R*Hmm) |
Size and Height of Grinding Ring(mm) |
Maximum Feed Length(mm) |
Product Granularity (mm) |
Capacity(t/h) |
Motor Power(kw) |
3R1510 |
3 |
150*100 |
480*100 |
15 |
0.2-0.044 |
0.3-1 |
7.5 |
3R2615 |
3 |
260*150 |
780*150 |
20 |
0.2-0.044 |
1-1.5 |
18.5 |
3R2715 |
3 |
270*150 |
830*150 |
20 |
0.2-0.044 |
1-3 |
22 |
3R3016 |
3 |
300*160 |
880*160 |
20 |
0.2-0.044 |
1-4 |
30 |
3R3018 |
3 |
300*180 |
990*180 |
20 |
0.2-0.044 |
3-5 |
30 |
4R3216 |
4 |
320*160 |
1073*160 |
25 |
0.2-0.044 |
2-6 |
37 |
4R3220 |
4 |
320*200 |
1075*200 |
25 |
0.2-0.044 |
2-7 |
37 |
5R4119 |
5 |
410*190 |
1300*190 |
35 |
0.2-0.044 |
2-8.5 |
75 |
5R4121 |
5 |
410*210 |
1300*210 |
35 |
0.2-0.044 |
3-9 |
75 |
5R4125 |
5 |
410*250 |
1300*250 |
35 |
0.2-0.044 |
5-10 |
75 |
6R4528 |
6 |
450*280 |
1600*280 |
40 |
0.2-0.044 |
3-16 |
132 |
Efficiency Grinding Mill Suitable For Non-explosive Materials Working Site:
