19Inches 3D 180°Hologram Showcase
Product Specifications
ComponentsNo. |
Name |
Technical Parameters |
Qty |
Note |
1 |
Shell |
Desktop/Floor Standing/Interactive （Optional） |
1PC |
Black, White, Silver (Optional) |
2 |
LCD |
19 inches |
1PC |
Original 19 "LCD module |
3 |
Host Machine |
Standalone Version/With Android/With Windows System（Optional） |
1 Full Set |
|
4 |
Power Supply |
125P |
1PC |
|
5 |
Cord |
1 Full Set |
||
6 |
Holographic Glass |
180° One Side View |
1 Full Set |
White glass/Grey glass |
7 |
Screen Assistant |
1PC |
||
8 |
All-in-One Capacitive touch screen |
ONLY included in Interactive Type |
1 Full Set |
SK190HD |
Brand |
HaoD |
|
Screen Size |
19“ |
Style |
Desktop/Floor Standing/Interactive （Optional） |
Display Scale |
5:4 |
Machine Size |
Please refer to end page |
Viewing Angle |
85° |
Best Viewing Distance |
＞0.5m |
Max Resolution |
1280×1024 |
Audio |
Stereo left and right channels |
Brightness |
250cd/m2 |
Image Quality |
Ultra HD |
Contrast |
1000:1 |
2D Video Format |
Support Common Video Formats |
Display Area |
376.32×301.056mm |
Interface Type |
USB/HDMI/Cable Interface |
Max Imaging Size |
376×301mm |
Holographic Glass |
White coating/Grey coating |
IV. Host Machine Configuration Parameters (Pick either of the following)
Standalone Version 1（PC or U Flash Disk can be connected to play） | |
Motherboard |
Industrial Grade |
Video Format |
Avi/mp4/ts/mkv/mpg/dat/vob 1920*1080/30fps |
Image Format |
Jpg/jpeg/bmp/png/ |
Music Format |
MP3 Sampling Frequency: 32K‐48KHz; Bit Rate:32K‐320Kbps |
Max Frame Rate |
20Mbps |
Port |
U Flash Disk/SD Card/HDMI |
Standalone Version 2（U Flash Disk Card Playing） | |
Motherboard |
Industrial Grade MP021 |
Video Format |
Avi/mp4/ 1920*1080/60fps |
Image Format |
Jpg/jpeg/bmp/png/ |
Music Format |
MP3 Sampling Frequency: 32K‐48KHz; Bit Rate:32K‐320Kbps |
Max Frame Rate |
20Mbps |
Port |
U Flash Disk/SD Card |
Motherboard |
RK3288 |
CPU |
Quad-core Cortex-A17+GPU Mail-T764, Up to 1.8G |
RAM |
2G DDR3(Up to 4G Supportive) |
Internal Memory |
EMMC8G/16G/32G (Optional) (Standard: 16G) |
OS |
Android 5.1 |
Port |
USB*2/RJ45(Network Interface)/TF Card |
Windows Version 1（Standard Configuration） | |
CPU |
Intel 1037U Dual-core dual-thread 1.8G |
Motherboard |
Mini-ITX Framework，Intel Bay trail SOC CS ChipSet |
RAM |
Kingston DDR3 1600 4G |
Hard Disk |
120G SSD |
GPU |
Integrating HD Graphic display core, supporting dynamic RAM allocation (DVMT) |
Power Supply |
Integrated Power Supply（12V） |
Network |
Realtec8111E Gigabit Interface Converter / 2.4G WiFi |
Windows Version 2（I3） | |
CPU |
Intel Core 3rd Generation I3 3217U Dual-core Quad-threaded 1.8G 17W |
Motherboard |
Mini-ITX Framework，HM76High-speed CS ChipSet |
RAM |
Kingston DDR3 1600 4G |
Hard Disk |
120G SSD |
GPU |
Integrated Intel HD Graphics 4000 |
Power Supply |
Integrated Power Supply（12V） |
Network |
Realtec8111E Gigabit Interface Converter / 2.4G WiFi |
Windows Version 3（I5） | |
CPU |
Intel Core 3rd Generation i5-3317U Dual-core Quad-threaded 1.7G 17W |
Motherboard |
Mini-ITX Framework，HM76 High-speed CS ChipSet |
RAM |
Kingston DDR3 1600 4G |
Hard Disk |
120G SSD |
GPU |
Integrated Intel HD Graphics 4000 |
Power Supply |
Integrated Power Supply（12V） |
Network |
Realtec8111E Gigabit Interface Converter / 2.4G WiFi |
Windows Version 4（I7） | |
CPU |
IntelCore 7th Generation I7-7500U Dual-core Quad-threaded 2.7G 15W |
Motherboard |
Mini-ITX Framework |
RAM |
Kingston DDR3 1600 4G |
Hard Disk |
120G SSD |
GPU |
Integrated Intel HD Graphics 620 |
Power Supply |
Integrated Power Supply（12V） |
Network |
Realtec8111E Gigabit Interface Converter / 2.4G WiFi |
V. Touch Screen Parameters
Infrared Touch Screen Parameters (Optional for Windows Version) | |||
Integration Method |
Seamless Built-in，Embedded |
Touch Screen Resolution |
3840*2160 |
Touch Technology |
Infrared multi-touch tech, standard ten-point touch control |
Touch Effective Identification |
≥2.5mm |
Screen Control |
fingers, touch pens and other opaque objects |
Computer Response |
System auto-scan |
Response Time |
5ms |
Transmission |
USB2.0 |
Location Accuracy |
±1.5mm |
||
Capacitive Touch Screen Parameters (Optional for Windows Version) | |||
Touch Method |
Finger or Soft Pen Cap |
Simultaneous Touch Points |
10 points |
Lifespan |
≥35,000,000 times |
||
Tolerable Touch Strength |
10-60g |
||
Storage Temp |
-15°C~40°C，＜90%RH；40°C~70°C，＜60%RH |
Relative Humidity |
10%~90%RH at 40°C, without condensation |
Response Time |
Light transmittance |
>85% |
|
Thickness |
1.6mm/Glass Thickness can be customized，(1.1mm)+TopITO Film(0.125mm) |
Durability |
Can work normally after touching 50,000,000 times on the same place |
VI. Electric Parameters
Electric Parameters | |||
Input Volt |
AC100-240V(50-60Hz) |
Working Temp |
-20℃~50℃ |
Speaker Power |
8Ω/5W*2 |
Storage Temperature |
-20℃~60℃ |
Overall Power |
＜20W |
Working Humidity |
10%-90% without condensation |
Standby Power |
＜3W |
||
Packing List | |||
Power Cord |
1PC |
Key |
1 Set |
Warranty Card |
1PC |
Certificate |
1PC |
Remote Control |
1PC（Only included in Standalone Version） |
||
