Ordinary Power Graphite Electrode

Product Name: Ordinary power graphite electrode

    Ordinary power graphite electrode is a conventional graphite electrode, compared with high-power graphite electrode, ordinary power graphite electrode has lower energy storage density and conductivity, but long service life, low price, but also suitable for many metallurgical industry fields in the melting and electrolysis process.

Technical parameters:

    Diameter: 75mm-600mm

    Length: 1000mm-2700mm

    Density: 1.60g/cm³-1.85g/cm³

    Flexural strength: 7Mpa-14Mpa

    Dielectric strength: 45KV/mm-55KV/mm

    Resistivity: 8μΩm-12μΩm

Use:

    Ordinary power graphite electrodes are mainly used in steel, non-ferrous metals, silicides, industrial manufacturing and other fields. In the application of high-temperature boiler industry such as electric arc furnace, ladle furnace, refractory materials, etc., it can be used for pouring iron, smelting molten steel and slag, manufacturing ferroalloys, and can also be used in aerospace buoys, microelectronics industry, semiconductor high-purity preparation and other industries.

    Ordinary power graphite electrode, low cost, long life, low temperature rise, high stability, trustworthy! In steel, non-ferrous metals, silicide, industrial manufacturing and other fields, it is widely used and provides a reliable guarantee for improving production efficiency.
