VENTURA BATTERY 5 OPzV 250 2V250Ah VENTURA

VENTURA BATTERY 5 OPzV 250 2V250Ah VENTURA

VENTURA BATTERY 5 OPzV 250 2V250Ah VENTURA

VENTURA Wang Ze Long 18210450914  VENTURA

VENTURA Wang Ze Long 18210450914  VENTURA

manufacturing technology

Ventura OPzV series tubular positive plate gel batteries are produced using advanced gel technology, integrating Ventura's over 100 years of battery research and production experience. They have comprehensively improved the reliability, safety, and efficiency of battery systems. Based on the design concept of application and environmental protection, the OPzV series batteries have maximum flexibility in installation location and method, Can provide the best solution for system integrators or end users.

Design Features

Technical features optimize the formula of battery active substances, with a battery capacity higher than the maximum capacity of 3170AH per unit according to DIN40742 standard, avoiding capacity loss and unbalanced gas recombination rate greater than 98% caused by parallel connection of batteries. The battery does not need to be added with water, and the low maintenance self discharge rate is extremely low. It is stored for 2 years and does not need to be replenished. The charging cycle life is greater than 1200 times @ 80% DOD, and can be quickly recharged. The maximum charging current is 40% C10. During normal use, no acid mist escapes, The battery can be installed easily in the office or main equipment room, and can be arranged horizontally or vertically according to the on-site space and load capacity.

specifications

The internal structure of electrolyte - The electrolyte is adsorbed in the colloid, with consistent concentrations up and down, and there will be no layering imagination; When leaving the factory, there is no free electrolyte, so the battery will not leak; The electrolyte density is 1.24g/ml ABS shell - high-strength ABS shell, which generally does not damage or deform in case of collision or overcharging. The safety valve is fireproof and flame-retardant, which effectively prevents external open flames from igniting internal gases. The copper pole with low internal resistance ensures safe discharge of large currents without heating. The tubular positive electrode plate - tubular die-casting positive electrode plate alloy structure is more dense, Enhanced corrosion resistance of positive electrode core - The positive electrode core rod is designed with protruding attachment thorns to increase the adhesion of active substances and prevent them from falling off.

VENTURA Wang Ze Long 18210450914  VENTURA

application area

Ventura OPzV series batteries have been widely used in fields such as communication, power, petrochemicals, metallurgy, financial centers, data centers, subways, exhibitions, and new energy worldwide.
