Help CenterMetal Honing Bar 40x3x2 900#
Related Products
-
Metal Diamond Honing BarUS$ 60 - 150MOQ: 1 Piece -
Dressing Pen Repair Corundum Grinding Wheel Grit 120 Hardness Hrc 22-27US$ 10 - 25MOQ: 10 Pieces
-
Diamond Abrasive Belt for Grinding Thermal Spray Industry 400#US$ 70 - 100MOQ: 1 Piece
-
Electroplated Diamond Internal Grinding Point for Grinding Zirconia Ceramics D12d10L70US$ 15 - 30MOQ: 10 Pieces
-
Green Silicon Carbide With 5NQ Abrasive General Grinding Wheel for Roll GroovesUS$ 20 - 25MOQ: 5 Pieces
Brief Introductions:
Type: |
Honing Stone |
Bond: |
Metal |
Application: |
Honing |
Specification: |
Customized |
Brand Mark: |
Moresuperhard |
Trade Terms: |
FOB |
Packages: |
Hard carton |
Delivery Time: |
15 workdays by express |
Introductions of Moresuperhard’s Metal Honing Bar
Honing is to use several whetstones installed on the circumference of the honing head, and the whetstones are radially expanded by the expansion mechanism, so that the whetstones are pressed against the hole wall of the workpiece, generating a certain pressure and contact area, and the honing head (or workpiece) rotates and reciprocates. The workpiece is ground at low speed during motion. The dimensional accuracy of the hole after honing is IT7-4, and the surface roughness can reach Ra0.32-0.04 microns.
Honing is mainly used for the machining of precision holes, such as engine cylinder holes, compressor cylinder holes, connecting rods, pump bodies and control blocks.
The honing tool is commonly known as the honing head. Several whetstones are installed on the circumference of the honing head, generally 4-6. Because the expanding mechanism expands the whetstone in the radial direction, a certain pressure is generated on the hole wall of the workpiece, and the honing head rotates. Movement and reciprocating linear motion, low-speed grinding and friction polishing of inner holes.
Honing can achieve the following technical indicators:
Honing inner hole size: 1 ~ 1200mm;
Honing inner hole depth: 1 ~ 20 000mm;
Dimensional accuracy: 0.002 ~ 0.01mm;
Applications of Moresuperhard’s Metal Honing Bar
– It is widely used in smoothing or finishing of holes of various shapes, with a diameter of 1 to 1200mm and a length of up to 12000mm. The working range of domestic honing machine: full 5 ~ 250mm, hole length 3000mm.
– It can be used for the processing of outer circle, spherical surface and inner and outer annular surfaces. Such as chrome-plated piston rings, tappet spherical surfaces and inner and outer rings of ball bearings, etc.
– It is used for mass production in automobile, tractor and bearing manufacturing, and is also suitable for mass production in various machinery manufacturing. Such as honing cylinder liners, cylinder holes, connecting rod holes, oil pump nozzles and hydraulic valve body holes, shaft sleeves, rocker arms and gear holes, etc.
– It is suitable for the processing of metal materials and non-metal materials. Such as cast iron, hardened and unhardened steel, hard aluminum, bronze, brass, hard chrome and carbide, glass, ceramics, crystal and sintered materials.
Service:
– Detailed Specifications can be customized!
– Provide after-sales service.
– Technical support on usage.
– Return and exchange of products for non-human reasons.
About us:
MORESUPERHARD is a professional manufacturer of grinding, cutting, polishing and dressing tools. Thanks to abundant experience in surface treatment, we design and offer a complete grinding and dressing solution to our customers in various industries. With innovative and creative development conception, MORESUPERHARD is tirelessly striving to provide excellent design, superior quality and perfect service to world-wide customers. More than 1000+ customers benefit from our professional technical services.
