HAWKER BATTERY AGV EV48-40 AGV Safe
Introduction
Hawker HuaDa EV series of power battery, is the international advanced level of lithium iron phosphate (LiFePO4) power battery system. With high energy density, long cycle life, excellent charge and discharge performance, good temperature performance, is a new generation of high security and high reliability of the green power supply.
This series of batteries is the use of the latest development of the battery management system (BMS), specifically for mobile mechanical equipment, online charging and wireless charging and design and production of power batteries, with advanced battery self-management, communication, alarm and short-term fast charge Complete function.
Product Features
● Excellent charge and discharge overvoltage and undervoltage protection
● provide analog output AO, SOC analog output 0 ~ 5V, user-friendly power monitoring
Note: SOC can only be used as a reference, can not be used as a decision.
● Provides a highly efficient passive equalization system
● Charge / discharge are all with short circuit insurance
● Panel LED power, system status display
● Rich interface, through the digital IO and 485 interface to achieve information exchange
● professional industrial design and material selection, sustainable work in the harsh industrial environment
● support high-power charge and discharge, to meet the needs of a variety of different industrial conditions
● wide temperature working environment conditions, -20 degrees -60 degrees
● small size
Dimensions specifications
Types
Battery size
Long*wide*high（mm）
Charge continuous current
Discharge continuous current
EV24-40
315*237*165mm
80A
20A
EV24-60
315*240*215mm
320*237*188mm
460*220*150mm
120A
30A
EV24-80
355*330*215mm
160A
40A
EV24-100
355*330*215mm
200A
50A
EV24-120
400*275*245mm
180A
60A
EV24-200
550*210*425mm
200A
100A
EV48-30
345*238*200mm
60A
30A
EV48-60
590*240*240mm
120A
30A
EV48-80
585*345*230mm
160A
40A
EV48-100
585*345*230mm
200A
50A
EV48-160
605*435*255mm
160A
80A
EV48-200
615*650*250mm
160A
100A
EV48-250
605*290*480mm
200A
125A
Performance specifications
project
Features
Overvoltage protection
3.7V (single string)
Undervoltage protection
2.8V (single string)
Charging parameters
Maximum 2C lasts for 10 minutes, 1C continues
Discharge parameters
Up to 1C continuous
Charge and discharge port form
Charge and discharge
fuse
Have
RS-485 communication
Have
Analog output AO
Have
Configurable DO output
Have
Power LED display
Have
Master switch
Have
Operating temperature
-20℃~60℃
Storage temperature
-20℃~70℃
Working humidity
Relative humidity of 10% to 80%, no condensation
cooling system
Passive natural cooling
Charger requirements
Lithium iron phosphate battery charger
Battery shell color
Toyota White (customizable)
