NI PXI-6722 Digital Control Board Module

Product Introduction

NI PXI-6722 is a digital control board module belonging to the PXI series of National Instruments (NI). The following are product details about the NI PXI-6722 module:

Digital input/output function: The NI PXI-6722 module provides 32 digital input/output channels. These channels can be configured as single ended input or output and support multiple voltage standards such as TTL, CMOS, and LVTTL. The module also provides voltage protection for 32 digital input/output lines, protecting the equipment from adverse effects such as overvoltage and electrostatic discharge.

High speed operation: The NI PXI-6722 module has high-speed operation capability and supports a maximum output rate of 10 MHz. It can output digital signals in the form of fixed frequency or timed pulses to meet the needs of fast control and data acquisition applications.

Flexible triggering function: This module has multiple triggering methods, including software triggering, hardware triggering, and external triggering. Users can configure trigger conditions as needed to ensure that the module performs corresponding actions when specific events occur.

Synchronous operation and multi module expansion: The NI PXI-6722 module supports multi module synchronous operation and can form a more scalable system with other PXI modules or NI hardware devices. This way, users can achieve more complex control and data collection tasks through the collaborative work of multiple modules.

Software support and development environment: The NI PXI-6722 module is compatible with NI's software development platform, including LabVIEW, LabWindows/CVI, and Measurement Studio. These tools provide a rich library of features and easy-to-use programming interfaces to help users quickly develop and deploy applications.

PXI standard compatibility: The NI PXI-6722 module complies with the PXI standard and can be inserted into any PXI compliant slot. This standardized design ensures interoperability of modules and system scalability.

Product image display
