Features
12VDC individually fused outputs
Circuit Short protection
Over-load protection
AC power LED indicator
Individual LED's for each output
Power ON/OFF switch
Unit maintains camera synchronization
Easy installation saves time and eliminates costly labor
100% full load burn-in test
Spare fuses included
2 years warranty
Specification
| Input Voltage | AC90-264V |
| Input Voltage Frequency | 50/60Hz |
| Output Specification | |
| Output Voltage | 12 VDC+10% |
| Total Output Current | 20A (1A/output,16channels for 16 sets security cameras) |
| Total Outputs | 250W |
| Fuse Type | glass Fuse |
| fuse Rateing | 1A/60V |
| size: | 483*44.45*250 |
| Protection | |
| General Protection | each output has individual fuse and LED indicator, when problem occurs, only affect the individual output, other outputs still working |
| Circuit Short Protection | when short condition occurs, individual fuse will open the circuit, when condition removed, PTC fuse will automatically back to close. |
| Overload protection | 105%-150% hiccup mode, auto-recovery |
| Over-voltage protection | 115%~135% |
| General Specifications | |
| Working temperature and humidity | -10ºC~+60ºC(Refer to output derating curve),20%~90%RH |
| Store temperature and humidity | -20ºC~+85ºC,10%~95%RH |
| Application | |
| CCTV | Camera, PTZ, IR Illuminators, Video Process Equipment, etc. |
Contact:
Web:
Email: mulviewcctv@mtlcctv.com
Skype:lancle0601
We chat: 13760462930
1. Q: What is your minimum order quantity?
A: The MOQ is 10 PCS.
2. Q: How does your factory do regarding quality control?
A: Our power adapters are real power and high efficiency. We do 100% full load aging and
testing before shipping.
3. Q: What is your warranty?
A: Our warranty is 2 years.
4. Q: What are the shipping ways you can offer?
A: We can delivery the goods by air/sea/express according to customers' requirements.
5. Q: What payment terms can be acceptable?
A:T/T, Western Union.
6. Q: How about your delivery time?
A: Bulk quantity within 10 working days normally.
7. Q: Do you provide samples of this product?
A: Yes, we can provide sample or trial order for test.
8. Q: Do you make OEM?
A: Yes, we can provide all kinds of OEM packing and labels as customers' request.
