Brand Name ABB
Place of Origin Sweden
Model Number PSTX1250-600-70

ABB Softstarter 1SFA898121R7000 motor soft starter PSTX1250-600-70 PSTX series 1250A 710kW

The softstarter PSTX1250-600-70 has a rated maximum operational current of 1250 A with an operating voltage span from 208...600 V AC. The rated control voltage is between 100...250 V AC at 50/60 Hz. PSTX features a three-phase control soft start and stop through a voltage or a torque ramp. It has built-in bypass for easy installation and energy saving. A RUN, TOR and Event signal is available from relay outputs in NO (normally open state). The PSTX has functions such as current limit, kickstart, analog output, EOL, motor heating and pump cleaning. PSTX also features features jog, braking, stand-still brake, diagnostics, sequence start and emergency/fire pump mode as standard.To interact with PSTX, it has a detachable full graphic display with IP66 and 4x outdoor rating. There are four ways to communicate with PSTX. It can be done by hardwire inputs Start/Stop/Reset of fault, and by three programmable digital inputs. Another popular option is the built-in Fieldbus communication Modbus RTU and incl optional ANYBUS modules with every major protocol such as for example Profinet, Profibus, Modbus TCP, Ethernet IP and others. Another way to communicate with PSTX is to use an external adaptor and a Fieldbus plug. PSTX is the complete alternative for any motor starting application. It’s suitable for medium to large-sized three-phase motors with nominal currents from 30...1250 A inline connection or 52...2160 A inside delta connection. Typical applications are, for example, pumps, fans, compressors, and conveyors.

PSTX Series Soft start/soft stop unit, 208…600 V - 50/60 Hz

 Model Number  Motor power (kW)

Nominal current(A)
400V 500V 690V
PSTX30-600-70 15 18.5 - 30
PSTX37-600-70 18.5 22 - 37
PSTX45-600-70 22 25 - 45
PSTX60-600-70 30 37 - 60
PSTX72-600-70 37 45 - 72
PSTX85-600-70 45 55 - 85
PSTX105-600-70 55 75 - 106
PSTX142-600-70 75 90 - 143
PSTX170-600-70 90 110 - 171
PSTX210-600-70 110 132 - 210
PSTX250-600-70 132 160 - 250
PSTX300-600-70 160 200 - 300
PSTX370-600-70 200 257 - 370
PSTX470-600-70 250 315 - 470
PSTX570-600-70 315 400 - 570
PSTX720-600-70 400 500 - 720
PSTX840-600-70 450 600 - 840
PSTX1050-600-70 560 730 - 1050
PSTX1250-600-70 710 880 - 1250
PSTX30-690-70 15 18.5 25 30
PSTX37-690-70 18.5 22 30 37
PSTX45-690-70 22 25 37 45
PSTX60-690-70 30 37 55 60
PSTX72-690-70 37 45 59 72
PSTX85-690-70 45 55 75 85
PSTX105-690-70 55 75 90 106
PSTX142-690-70 75 90 132 143
PSTX170-690-70 90 110 162 171
PSTX210-690-70 110 132 184 210
PSTX250-690-70 132 160 220 250
PSTX300-690-70 160 200 257 300
PSTX370-690-70 200 257 355 370
PSTX470-690-70 250 315 455 470
PSTX570-690-70 315 400 560 570
PSTX720-690-70 400 500 710 720
PSTX840-690-70 450 600 800 840
PSTX1050-690-70 560 730 1000 1050
PSTX1250-690-70 710 880 1200 1250

Note: Due to a lot of product models, please contact us for more detailed . Looking  forward to work with you.
