Cheap And High Quality SMT Off Line Optical Inspection Foundation Magic Xray 3D Automatic

Cheap And High Quality SMT Off Line Optical Inspection Foundation Magic Xray 3D Automatic

WA: +8615019413375

Main Description :

1. Closed Tube From HAMAMATSU Japan.

2. Imported Detector from Korea Rayence.

3. Micro-focus

4. Spot size down to 5µ

5. 5″ x 5″ or 4″ x 3″ high resolution and ultra resolution CMOS digital flat pane imagel detectors

6. 60° camera tilt for oblique angle viewing

7. 22″ x 18″ Inspection Stage with 350° Rotation

8. Color mapping camera with zoom window provides easy location and identification of faults

9. Z axis movement of the x-ray tube and detector

10. Computer controlled kV and mA settings

11. Computer controlled variable speed X-Y stage (and rotate)

12. Simple point and click, intuitive GUI provides access to create advanced inspection routines

13. All s/w tools standard including (but not limited to)

14. BGA Void detection and automatic calculations

15. Mobile Flex Cable FPC x-ray inspection

16. SMT Mounting and PCB X-ray inspection

17. Easy macro recording for intuitive step and repeat programming

18. Various measuring tools for TH, radius, area, perimeter, etc

19. Industrial PC with Windows 7 , 24″ LCD flat panel display

∑ S7200 IC IGBT xray machine for welding soldering inspection

Application:

BGA Solder Ball Bubble Caculation

IC Chips Inside Connector Wire Inspection

PCB FPC Mobile Flex Cable Soldering Inspection

Inspect the Voids under Joint

PCBA BGA/IC LED Aliminum die casting Battery connector inspecting

Semiconductor package
Electronic connector module.
Original Package X-Ray
Aerospace components
Medical appliances

Automation components
