Acrel WHD48-11/C Switchgear Humidity & Temperature Controller RS485 Communication Temperature Data Collection
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2003
Factory Size:
3,000-5,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Temperature Alarm Deviecs Acrel WHD20R-11/JC Temperature & Humidity Controller for Switch CabinetNegotiableMOQ: 1 -
Acrel WHD20R-22/C Two Channels Temperature & Humidity Controller With CE CertificationNegotiableMOQ: 1
-
Acrel WHD46-22 Temperature & Humidity Controller With Sensors for Terminal BoxNegotiableMOQ: 1
-
Acrel WHD46-11 Din Rail Measuring Temperature and Humidity With Sensors for Switch CabinetNegotiableMOQ: 1
-
Acrel WHD46-33 Din Rail Measuring Temperature and Humidity With Sensors for Terminal BoxNegotiableMOQ: 1
Product Description
The controller for temperature and humidity is suitable for adjustment and control of temperature and humidity in equipments of high voltage switchgear, terminal box, ring network panel, box transformer substation etc. It can effectively protect relevant equipment from faults resulting from excessive low or high temperature, creepage or
flashover etc.from humidity or condensation.
These products meet the requirements of GB/T 15309-1994.
flashover etc.from humidity or condensation.
These products meet the requirements of GB/T 15309-1994.
Details
Type |
Function |
Sensor (Pcs) |
Mounting mode |
WHD48-11/c |
one channel temperature, humidity control |
WH-3(1) |
panel 44.5*44.5mm |
1-2 port：power supply ( AC/DC85-265v)
17-18 port: the Heating control(passive contact,connect with Heat equipment)
15-16 port: the Fan control(passive contact,connect with Fan)
30-31 port:RS485 communication port(modbus-rtu protocol)
3-4-5-6 port:the sensor (connect with temperature&humidity sensor. 3 connect to V+ ;4 connect to Clk;5 connect to Data;6
connect to V-)
3-4-5-6 port:the sensor (connect with temperature&humidity sensor. 3 connect to V+ ;4 connect to Clk;5 connect to Data;6
connect to V-)
