1734-IA4 Original US AB Rockwell PLC Module Warranty One Year POINTIO Series Negotiated Price

The 1734-IA4 is a POINT I/O 120 volt AC input module in the Allen-Bradley PLC 1734 series. The digital module weighs about 1.09 ounces. In addition, it has an open case type rating of 2.21 x 0.47 x 2.97 inches. The compact design of the module makes installation easy and can be installed horizontally or vertically. The 1734-IA4 has 2 to 120 volts AC input and 8 key switch positions, and supports ControlNet, DeviceNet, and EtherNet/IP networks.

The 1734-IA4 has a POINT bus current of 75 mA and a maximum DC voltage of 5V. It has a power consumption of 0.50 W at 132 volts AC, a heat dissipation of 1.71 BTU/hour at 132 volts AC, and a rated input impedance of 10.6 kiloohms. The external or input AC supply voltage of the digital module is a nominal value of 120 volts AC at a frequency of 60 Hz. Thus, the 1734-IA4 can be used at AC voltages of 85 to 132 volts and frequencies of 47 to 63 Hertz
