Help CenterBangzhao Electric High Voltage 460VDC 256kwh Lithium Battery Storage System With EMS for Island Energy Storage System
Related Products
-
220-380V to 277-480V Voltage Converter Single Phase to Three Phase Converter 30kw Digital Phase ConverterUS$ 1000 - 3000MOQ: 1 Piece -
Single Phase 220Vac Input to 50-750VDC Output 1-60A Battery Charger Can Adjustable Voltage and CurrentUS$ 800 - 3000MOQ: 1 Piece
-
15kw Car Power Inverter (Explosion-proof Inverter) With )with 250-400VDC Input Low Frequency Converter With Ex-proof CertificateUS$ 1000 - 3000MOQ: 1 Piece
-
Stainless Steel Chassis Railway Backup Power Sine Wave Inverter With High Voltage 525V AC OutputUS$ 1000 - 3000MOQ: 1 Piece
-
500-900VDC PV Input Low Frequency dc to ac Pure Sine Wave Power Inverter 500KW 440V-480VAC 3 Phase OutputUS$ 35000 - 50000MOQ: 1 Piece
Bangzhao Electric ESS lithium battery system is composed of lithium battery modules, BMS system, PV charge controller or AC/DC Charger, central control unit CCU, temperature detector, integrated structure and other parts; the solar panels in the system are battery storage and power for output; BMS module completes the detection and control of voltage, current, temperature, SOC, SOH and charging and discharging related parameters of power battery pack; photovoltaic controller and inverter realize bidirectional AC/DC function to meet the charging and discharging conversion demand of power battery pack; each detector is used to monitor the ambient temperature in real time to ensure the safety of the system.
1) Bangzhao Company’s BMS battery management system uses automotive-grade RAM, AD sampling chip, stable and reliable performance, and a 5-inch high-definition touch screen, which is simple and convenient to operate.
2) The power inverter adopts the imported Mitsubishi sixth-generation IPM intelligent power module design scheme, with power frequency isolation, simple structure, low failure rate and high efficiency.
3) The solar controller adopts IGBT module design, PWM algorithm, stable and reliable charging efficiency, and can be linked with the BMS system to strengthen the protection of the battery.
4) The solar combiner box adopts DC 1000v, with LED indicating fuse holder, DC professional surge protector, and high-power anti-reverse module.(optional)
5) The product communicates with the monitoring platform in real time through RS232, CAN communication interface, and reports various records in time to ensure real-time monitoring of the battery pack of the monitoring platform
6) The system software supports remote and local upgrade functions
7) 3000 cycles life span is more than 10 years
8) 20kwh to 1000kwh can customizable production
9) The color and size of the case can be customized according to requirements and OEM
