Description
The network cabinet has evolved from a full-panel structure in the past to a plug-in and plug-in structure with a certain size series. The assembly arrangement of the plug-in box and the plug-in is divided into two types: horizontal arrangement and vertical arrangement. The network cabinet materials generally use thin steel plates, steel profiles of various cross-section shapes, aluminum profiles and various engineering plastics. In addition to welding and screwing, the frame of the network cabinet is also bonded.
Material and process surface treatment: degreasing, pickling, phosphating, electrostatic spraying
Advantage:The cabinet body is of frame structure with a static load bearing capacity of 800KG; Toughened glass front door and high-density mesh rear door can meet the requirements of equipment protection, ventilation and heat dissipation, and external observation of machine operation status; The side doors on both sides of the cabinet can be opened quickly, which is convenient for installation and maintenance; The tray can be adjusted up and down freely according to user requirements; The accurate position of each "U" is marked on the vertical installation beam of the cabinet, which is convenient for users to install; beautiful; Castors and supporting feet can be installed at the same time; The door strip with ventilation hole is convenient for ventilation and heat dissipation;
Specification:
Capacity(U) Wall Cabinet(Width*Height*Depth)
4 600*280*450mm
6 600*350*450mm
9 600*500*450mm
12 600*650*450mm
15 600*750*450mm
*We can also provide 18u, 22u, 27u, 32u, 36u, 42u.
*WE SUPPORT OEM&ODM SERVICE.
