Copper Cable Terminals Non-Isolated -SC (JGK) Type
- T/T L/C
You May Like
Product Details
| Brand Name | OMU | Place of Origin | China | |
| Model Number | SC (JGK) | Type | Lug |
Product Description
Specificaitons | Dimensions(mm) | Code No. | |||
D | d | L | |||
SC(JGK)-1.5 | 3.5 | 2.1 | Φ4.2, Φ5.2 | 19 | OMU-SC-001 |
SC(JGK)-2.5 | 4 | 2.5 | Φ4.2, Φ5.2, Φ6.2 | 19 | OMU-SC-002 |
SC(JGK)-4 | 4.8 | 3.4 | Φ5.2, Φ6.2 | 20.5 | OMU-SC-003 |
SC(JGK)-6 | 5.5 | 4.1 | Φ5.2, Φ6.2, Φ8.2 | 23 | OMU-SC-004 |
SC(JGK)-10 | 6.5 | 5.1 | Φ5.2, Φ6.2, Φ8.2, Φ10.5 | 26.5 | OMU-SC-004 |
SC(JGK)-16 | 8 | 6.4 | Φ6.2, Φ8.2, Φ10.5 | 29.5 | OMU-SC-006 |
SC(JGK)-25 | 9 | 7 | Φ6.2, Φ8.2, Φ10.5, Φ12.5 | 33 | OMU-SC-007 |
SC(JGK)-35 | 10.5 | 8.5 | Φ6.2, Φ8.2, Φ10.5, Φ12.5 | 36 | OMU-SC-008 |
SC(JGK)-50 | 12 | 9.8 | Φ8.2, Φ10.5, Φ12.5, Φ14.5 | 43.5 | OMU-SC-009 |
SC(JGK)-70 | 14.5 | 11.9 | Φ8.2, Φ10.5, Φ12.5, Φ14.5 | 49.5 | OMU-SC-010 |
SC(JGK)-95 | 16 | 13 | Φ8.2, Φ10.5, Φ12.5, Φ14.5, Φ16.5 | 53.5 | OMU-SC-011 |
SC(JGK)-120 | 19 | 15.4 | Φ10.5, Φ12.5, Φ14.5, Φ16.5 | 61 | OMU-SC-012 |
SC(JGK)-150 | 20.5 | 16.7 | Φ10.5, Φ12.5, Φ14.5, Φ16.5 | 68 | OMU-SC-013 |
SC(JGK)-185 | 23.5 | 19.3 | Φ12.5, Φ14.5, Φ16.5 | 75 | OMU-SC-014 |
SC(JGK)-240 | 26 | 21.2 | Φ12.5, Φ14.5, Φ16.5 | 85 | OMU-SC-015 |
SC(JGK)-300 | 30 | 24 | Φ12.5, Φ14.5, Φ16.5, Φ20.5 | 95 | OMU-SC-016 |
SC(JGK)-400 | 34 | 27.6 | Φ12.5, Φ14.5, Φ16.5, Φ20.5 | 111 | OMU-SC-017 |
SC(JGK)-500 | 38 | 31.6 | Φ16.5, Φ20.5 | 123 | OMU-SC-018 |
SC(JGK)-630 | 45 | 37.6 | Φ16.5, Φ20.5 | 140 | OMU-SC-019 |
SC(JGK)-800 | 50 | 39 | Φ20.5 | 170 | OMU-SC-020 |
SC(JGK)-1000 | 56 | 44 | Φ20.5 | 200 | OMU-SC-021 |
