Wide temperature DG21106
- 40000 Piece / Pieces per Month
- Tianjin
- 30 days
- negative segment character running machine lcd display,practical STN,blue backlight, fitness equipment
- digital fire alarm installation module display, HTN segment display with blue led lcd panel
- negative autoreclose circuit-breaker lcd display, segment module with blue led
- charger negative character lcd display,white led ,battery segment small flexible display
- character small charger lcd display ,custom battery display ,white led
- segment positive temperature time clock lcd display,blue TN white backlight
Product Details
Place of Origin: | China |
Product Description
Wide temperature DG21106
Product Usage: Electricity meter panel
Power Consumption Characteristics: Ultra-low power consumption
LCD Product Type: STN
Perspective Features: Wide Angle of view
Temperature Characteristic: Wide temperature
Polarizer Type: Transmissive
DG21106 energy meter lcd display
1. Boundary Dimension: 71.0*(25.2+21.2)mm
2. Strong Viewing Direction: 6 o’clock
3. V-OP: 3.0V±0.15V
4. Drive Method: 1/8 DUTY; 1/3 BIAS
5. Operating Temperature: -20℃~75℃
6. Storage Temperature: -30℃~80℃
7. Polarizer: Transmissive/Positive(UV)
8. Display Type: STN YELLOW/GREEN
9. Penetration Frequency: 64Hz~128Hz
10. Product Usage: Electricity Meter Panel
Custom LCD Panel: According to customer’s needs
LCD Model | TN、HTN、STN(Gray, Teal, Blue)、VA |
Polarizer | Reflection、Transmissive、Positive |
Display Mode | Positive Display Negative Display |
Boundary Dimension | The Large Glass: Length*Width(mm) The Small Glass: Length*Width(mm) |
Visual Size | Length*Width、(mm) |
Temperature | Operating Temperature(℃) Storage Temperature(℃) |
V-OP | 3V、3.3V、5V |
Drive Method | 1/4DUTY; 1/3BAIS |
Connection Type | Metal PIN、Conductive Strip、FPC PIN Number, PIN Length, PIN Spacing |
Strong Viewing Direction | 6: 00、12: 00、3: 00、9: 00 |
ITO Thickness | 0.55mm、0.7mm、1.1mm |
Seal/Printing | ● Yes or No ● Color (Red, Yellow, Green, Blue) |
Our company specializes in the production and design of segment code LCD screen and drive module, with 36 years of experience in the design and production of segment code LCD screen, we can provide you with good design suggestions for your products, our products are of good quality, low mold cost, excellent price, large quantity and more preferential, and we promise to provide after-sales service. Have any demand, we will try to meet you, look forward to serving you. We are custom lcd display manufacturer.
