Furuno Digital Depth and Temp Sensor DST-810MSF
- T/T
You May Like
Product Description
Model：Digital Depth and Temp Sensor DST-810MSF
Transducer Features
Airmar B617V Housing Style Transducer
The DST-801MSF offers depth, speed, and temperature in a single, 51 mm (2”) fitting. Only one hole through the hull simplifies the installation — an attractive feature for boat builders and boat owners alike. Patented, speed-signal-processing and upgraded 5 Hz (5X per second) speed-through-water enhancements provide excellent paddlewheel accuracy below 5 knots (6 MPH) and smooth linear output at all vessel speeds. The transducer’s wide, fan-shaped, fore-aft beam is able to find bottom even when installed on steep deadrise hulls or heeling sailboats. You also get true water-temperature readings with the DST-810MSF's reliable temperature sensor.
The DST-810MSF features a new Wireless connectivity to Airmar's CAST App, allowing you to calibrate the sensor, add depth offsets, and more.
Standard Features
Depth, speed, and temperature in one compact bronze housing
Fast-response temperature sensor provides ±0.2°C (±0.1°F) accuracy
Weight: 1.6 kg (3.5 lb)
Acoustic Window: Urethane Hull
Deadrise: Up to 22°
Data Update Rate: 1 per second
Minimum Sounding Depth: 0.5 m (1.6’)
Maximum Sounding Depth: 70 m (230’)
Pressure Rating: 3 m (10’)
Pulse Rate: 20,000 p/nm* (5.6 Hz per knot)—*p/nm = pulses per nautical mile
Smart Sensor Supply Voltage at 100% Sound Power Output: 11.5 VDC to 25 VDC
Supply Current: 40 mA
Standard Cable Length: 6m
NMEA 2000® Load Equivalency Number (LEN): 4
Please send email to us for more details:
sales@malinsmarine.com
Product Introduction
Malins Marine Service Co.,Ltd.
Was established in 2010 as a wholesaler and service provider of marine navigation & communication equipment.During the past years, the company has expanded by several folds in terms of size as well as business turnover.
The company started up in 2010 with one office and two persons and now has three offices and one warehouse, with working team of over 20 persons.As China continues to develop, Malins Marine is in a strong position not only to utilize the resources available domestically but also to introduce foreign shipyards and marine prodcuts to the ship owners and ship managers of China. Malins Marine collaborates closely with worldwide leading and specialized maritime equipment suppliers and manufacturers in order to provide our wide range of clients a full breadth of products and genuine spare parts as well.
With the support of a global network of well-known manufacturers, we are able to meet the growing & challenging demands of our customers from a sustainable development perspective.One-stop service for spare parts supplied and service, provide economic solution for ship owners & managers. To fully meet our customers’ requirements, we also specialise in navigation and communication systems, statutory annual radio surveys, annual performance tests as well as after-sales services. Our comprehensive line includes high quality electronics for navigation, communications, and safety & security applications. Over the years, we have built our service net covered China Coastal Port from north to south. Most of attending engineer trained by major makers and we owned genuine spare parts of kinds of makers in Shanghai head office.
Sales & Service
Sales navigation & communication equipment & spare parts
Service: installation/commission/repairing/calibration
Furuno, JRC, Sailor (Thrane&Thrane)- Cobham, Yokogawa, Tokimec (Tokyo Keiki), Raytheon Anschutz, Sperry, SAM Electronics, L3, Kelvin-Hughes, Mcmurdo, Jotron, Danelec, Samyung, Highlander, Headway, Rutter, Netwave, Simrad, JMC, Taiyo, STN Atlas, Cassens & Plath, C-plath, Teledyne, Consilium, Kongsberg, Samsung....
