Automatic 110V MOSFET MMA/TIG/CUT welding machine cutter CT-312

Name: Automatic 110V MOSFET MMA/TIG/CUT welding machine cutter CT-312
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Features

1. Advanced inverter technology, energy-efficient and low noise.
2. Use compressed air as cutting gas source, cost-effective.
3. Air pressure and cutting current adjustable.
4. Easy operation, narrow cutting seams, smooth cutting performance and less deformation.
5. Circuit protection against over current, over voltage and over heat.
6. Suitable for cutting carbon steel, stainless steel, alloy steel, copper and aluminum, etc.
7 .Widely used in iron structure construction, manufacturing and automobile maintenance.

Technical Specifications

ITEM	UNIT	CT-312	CT-416	CT-520
Input Power Voltage	V	AC380V±10%	AC380V±10%	AC380V±10%
Input Power Frequency	Hz	50/60	50/60	50/60
Rated Input Capacity	KVA	3.5	4.5	5.5
Output Current Range (MMA)	A	10-110	10-140	10-160
Output Current Range (TIG)	A	10-120	10-160	10-190
Output Current Range (CUT)	A	10-30	10-40	10-50
No-load Voltage	V	230	240	240
Rated Duty Cycle	%	60	60	60
Arc Start		HF	HF	HF
Power Factor	cosΦ	0.93	0.93	0.93
Air Pressure	mpa	0.2-0.4	0.2-0.4	0.2-0.4
Protection Grade		IP21S	IP21S	IP21S
Dimensions	MM	410155300	460210360	510210360
weight	Kg	8.6	12.7	17.8
