Tig Welder ac dc Aluminium Welding Machines
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Cutting Machine Arc Bending Portable Cut Steel Welding Machine
-
High Quality Cutting Iron Machine Cut-100
-
Ct 312 Dc Mma Tig Cut Welder Ac/dc Inverter Tig/mma Pulse Welder MIG Welders Mosfet Inverter Welder Welding Equipment DC MOTOR
-
Belt Driven Air Compressor Z-0.036 30L 1kw 8 Bar Portable 220V 69kg CE
-
MGB-2025, 25L Sell Manual Air Compressor Philippines Portable AC POWER PISTON 220V Lubricated 23KG CE
-
MGB-3050, 50L Factory Lowest Price Air Compressor Portable
Product Description
Product Description
Features
(1)Apply MOSFET switching power supply and PWM technology ,energy-efficient and low noise.
(2)Both AC and DC TIG welding available,Mild arc ,easy wire filling and good shaping.
(3)Thermal and voltage overload protection ensures long life internal components.
(4)High-frequency arc starer boosts the current during starting to make striking an arc easier and increase productivity.
(5)Applicable for DC TIG welding of carbon steel, stainless steel,alloy steel,and other non-ferrous metals ,
as well as AC TIG welding of aluminum and aluminum alloy products.
ITEM | UNIT | WSME-200 | WSME-250 | WSME-315 |
Input power voltage | V | AC220V | AC220V | AC400V |
Input power frequency | HZ | 50/60 | 50/60 | 50/60 |
Rated input capacity | KVA | 4.6 | 6.4 | 9 |
Ac balance control range | % | 20-80 | 20-80 | 20-80 |
Output current range | A | 200 | 250 | 315 |
No-load voltage | V | 56 | 56 | 56 |
Downslope time | S | 0-5 | 0-5 | 0-5 |
Arc start | HF | HF | HF | |
Power factor | cos | 0.93 | 0.93 | 0.93 |
Protection grade | IP21S | IP21S | IP21S | |
Rated duty cycle | % | 60 | 60 | 60 |
dimensions | mm | 590x345x485 | 590x345x485 | 590x345x485 |
Weight | kg | 23 | 32 | 38 |
ACCRESSIORES
The default accessories
4M QQ-150 TIG torch 1.8M Electerde holder 1.2M earth clamp Brush & Mask
Can match it with something else
Welding gloves
Tungsten needle
gas tube
Packing & Delivery
Company Introduction
Certifications
Exhibition
FAQ
MOQ:
- The different products with different MOQ. Contact us with more details.
- If with stock, 1-5 sets could be acceptable as well.
Payment:
- TT payment would be preferred: usually 30% deposit and the balance before shipment
Delivery time:
- Within 20 days after confirming the payment
Sample Issue
- Once price and order confirmed, we will be glad to send you the required samples for reference.
First time to use this kind of machine
- There is an English manual or guide video that show you how to use machine.
- If you still have any question, please contact us by e-mail /phone / online service.
If any problem with machine after receiving
- 24 hours to support by E-mail/calling
- Free parts could be sent to you in machine warranty period.
Why choose us?
- We are welding machine MANUFACTURER,so we can offer better price and after-sale service and shorter delivery date.
- We use all new components,IGBT tube, diode,capacitor and so on imported components.
- We adopt SMT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of repairing,we just need to change the bad pcb board.
- We provide Warranty period of 1 to 2 years for all our items.
