220V Digital RETOP Tig 200p Acdc Pulse

220V Digital RETOP Tig 200p Acdc Pulse thumbnail-1
220V Digital RETOP Tig 200p Acdc Pulse thumbnail-2
220V Digital RETOP Tig 200p Acdc Pulse thumbnail-3
220V Digital RETOP Tig 200p Acdc Pulse thumbnail-4
220V Digital RETOP Tig 200p Acdc Pulse thumbnail-5
220V Digital RETOP Tig 200p Acdc Pulse photo-1
220V Digital RETOP Tig 200p Acdc Pulse photo-2
220V Digital RETOP Tig 200p Acdc Pulse photo-3
220V Digital RETOP Tig 200p Acdc Pulse photo-4
220V Digital RETOP Tig 200p Acdc Pulse photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Contact Supplier Request Quote Chat Now
Jingjiang Fuji Technology Co., Ltd.
Gold Verified Supplier
4Yrs
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description

Features

(1) Digital control,MCU technology,automatic parameter saving.


(2)IGBT inverter technology.

(3) Hight frequency toguarantee lighter and smaller welder with higher efficiency.

(4) Multi-function design to meet various welding demands.It is suitable for DC TIG welding,MMA welding,spot welding,pulse TIG welidng,AC TIG welding etc.

(5) Simple-to-use operator interface.

(6) Less spatter,stable arc and good shaping.


(7)Applicable for DC TIG welding of carbon steel,stainless steel,alloy steel,and other non-ferrous metals.especially for AC TIG welding of aluminum and aluminum alloy products.

ITEM
UNIT
TIG-200PACDC
Input power voltage
V
AC230V
Input power frequency
Hz
50/60
Input Current
A
31
Rated input capacity
KVA
7.1
Output current range(TIG)
A
5-200A
Output current range(MMA)
A
10-160
Pre-flow Time
S
0.1-10
Post-flow Time
S
0.5-15
Down Slope
S
0-15
Balance

15-85
Arc Starting

HF
AC Frequency

20-250
Pulse Frequency

0.2-200
No-load voltage
V
56V

35%
200
Rated Duty Cycle
60%
129

100%
100
Electrode Diameter
mm
1.5-4.0
Efficiency
 %
85
Protection grade

IP22S
Insulation Class

B
Dimensions
mm
440*210*360
Weight
KG
11
ACCRESSIORES
The default accessories
4M QQ-150 TIG torch 1.8M Electerde holder 1.2M earth clamp Brush & Mask
Can match it with something else
Welding gloves
Tungsten needle
gas tube
Company Introduction
Certifications
Exhibition
FAQ

MOQ:

  • The different products with different MOQ. Contact us with more details.
  • If with stock, 1-5 sets could be acceptable as well.



Payment:

  • TT payment would be preferred: usually 30% deposit and the balance before shipment

Delivery time:

  • Within 20 days after confirming the payment

Sample Issue

  • Once price and order confirmed, we will be glad to send you the required samples for reference.

First time to use this kind of machine

  • There is an English manual or guide video that show you how to use machine.
  • If you still have any question, please contact us by e-mail /phone / online service.

If any problem with machine after receiving

  • 24 hours to support by E-mail/calling
  • Free parts could be sent to you in machine warranty period.

Why choose us?

  • We are welding machine MANUFACTURER,so we can offer better price and after-sale service and shorter delivery date.
  • We use all new components,IGBT tube, diode,capacitor and so on imported components.
  • We adopt SMT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of repairing,we just need to change the bad pcb board.
  • We provide Warranty period of 1 to 2 years for all our items.
Action now
Why choose Retop?
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.

b. We use all new components,mosfet tube, diode, capacitor and so on imported components.

c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.

d. We provide Warranty period of 1 year for all our items
