TIG-200P AC DC Small Gas Tig Welding Machine for Aluminum Welding Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Double Voltage Cut40 50 Plasma Cutting Machine Cut 50NegotiableMOQ: 1 -
High Quality Low Power V-0.25, 100L 2.2kw Direct Driven Air CompressorNegotiableMOQ: 1
-
High Quality Automatic OF-600-12L 1 hp Oil Free Medical Air CompressorNegotiableMOQ: 1
-
Funny Welding Helmet Welder Unique Welding Protective MaskNegotiableMOQ: 1
-
High Performance Over 20 Years Experience Cheap Welding HelmetsNegotiableMOQ: 1
Product Description
Features
1. Digital control, MCU technology, automatic parameter saving, IGBT inverter technology.
2. High frequency to guarantee lighter and smaller welder with higher efficiency.
3. Multi-function design wo meet various welding demands. It is suitable for DC TIG welding, MMA welding, spot welding, pulse TIG welding, etc.
4. Simple-to-use operator interface.
5. Less spatter, stable arc and good shaping.
6. Compete with TIG torch, electrode holder, earth clamp, face mask, hammer.
2. High frequency to guarantee lighter and smaller welder with higher efficiency.
3. Multi-function design wo meet various welding demands. It is suitable for DC TIG welding, MMA welding, spot welding, pulse TIG welding, etc.
4. Simple-to-use operator interface.
5. Less spatter, stable arc and good shaping.
6. Compete with TIG torch, electrode holder, earth clamp, face mask, hammer.
TIG-200P AC DC small gas tig welding machine for aluminum welding price
Technical Specifications
ITEM |
UNIT |
TIG-200P AC/DC |
Input Power Voltage |
V |
AC230V±10% |
Input Power Frequency |
Hz |
50/60 |
Input Current |
A |
31 |
Rated Input Capacity |
KVA |
7.1 |
Output Current Range (TIG) |
A |
5-200 |
Output Current Range (MMA) |
A |
10-160 |
Pre-flow Time |
S |
0.1-10 |
Post-flow Time |
S |
0.5-15 |
Down Slope |
S |
0-15 |
Balance |
15-85 |
|
Arc Starting |
HF |
|
AC Frequency |
20-250 |
|
Pulse Frequency |
0.2-200 |
|
No-load Voltage |
V |
56 |
Rated Duty Cycle |
35% |
200 |
Rated Duty Cycle |
60% |
129 |
100% |
100 |
|
Electrode Diameter |
mm |
1.5-4.0 |
Efficiency |
% |
85 |
Protection Grade |
IP22S |
|
Insulation Grade |
B |
|
Dimensions |
MM |
440*210*360 |
weight |
Kg |
11 |
Related products
Company Introduction
Certifications
Exhibition
Action now
Why choose Retop?
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
