High Quality Small Air Cooled 2 Cylinders 4 Stroke SCDC Diesel Engine R292/R2V88

High Quality Small Air Cooled 2 Cylinders 4 Stroke SCDC Diesel Engine R292/R2V88 thumbnail-1
High Quality Small Air Cooled 2 Cylinders 4 Stroke SCDC Diesel Engine R292/R2V88 thumbnail-2
High Quality Small Air Cooled 2 Cylinders 4 Stroke SCDC Diesel Engine R292/R2V88 thumbnail-3
High Quality Small Air Cooled 2 Cylinders 4 Stroke SCDC Diesel Engine R292/R2V88 thumbnail-4
High Quality Small Air Cooled 2 Cylinders 4 Stroke SCDC Diesel Engine R292/R2V88 photo-1
High Quality Small Air Cooled 2 Cylinders 4 Stroke SCDC Diesel Engine R292/R2V88 photo-2
High Quality Small Air Cooled 2 Cylinders 4 Stroke SCDC Diesel Engine R292/R2V88 photo-3
High Quality Small Air Cooled 2 Cylinders 4 Stroke SCDC Diesel Engine R292/R2V88 photo-4
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Contact Supplier Request Quote Chat Now
Jingjiang Fuji Technology Co., Ltd.
Gold Verified Supplier
4Yrs
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Promotion
Product Description

High quality Small air cooled 2 cylinders 4 stroke SCDC diesel engine R292/R2V88











engine
Model
R2V88
Type
2 cylinders, V type , 4 stroke ,air cooled
Rated power (KW)
14
13
Rated HP (HP)
17.68
19.04
RPM (r/min)
3000
3600
Max torque(N.m/r/min)
45/2600
45/2600
Bore ×stroke (mm )
80*79
Displacement (ml)
870
Start method
Electronical
Oil volume (L)
2.7
Fuel consumption (g/kW.h)
≤ 275
≤ 285
 weight (KG)
59
Dimension (L x W x H) (mm)
550*391*459










engine
Model
R292
Type
2 cylinders, V type , 4 stroke , Air cooled
Rated power (KW)
14.5
16
Rated HP (HP)
19.72
21.76
RPM (r/min)
3200
3600
Max torque(N.m/r/min)
50/2400
52/2400
Bore ×stroke (mm )
92*75
Displacement (ml)
997
Oil volume (L)
2.5
Start method
Electronical
Noise(7 meters )(dB)
≤ 86
 weight (KG)
78
Detailed Images
