8kw 20kw 100kw 500kw 1000kw SCDC Diesel Engine for Generator Set
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Brand New 30kw Marine Genset 4BTA3.9-GM47NegotiableMOQ: 1 -
Genuine Water Cooled 50HZ 200kva Diesel Marine Engine Generator SetNegotiableMOQ: 1
-
KTA50G8 Diesel Generator SetNegotiableMOQ: 1
-
10KW Water Cooled Silent Diesel Machines Engine Genset EV80 With CanopyNegotiableMOQ: 1
-
High Quality 12KW Air Cooled Silent Diesel Generator R292 With CanopyNegotiableMOQ: 1
500kw generator set
|
Rated power
|
8kw-1000kw |
| Model | # |
| Type | open type,soundproof,weather proof type, mobile type as your required |
| Rated voltage | 400/230V,240/120V etc,as required |
| Rated frequency | 50Hz/60HZ. |
| Rated current | 14.4-1800A |
| Rated speed | 1500/1800rpm |
| Connection type | single phase or 3P4W |
| Voltage governor | AVR |
| Start method | electric start
|
|
Brand
|
Ps |
| Engine model | 1003G,1003TG,1004G,1004TG,1006TG1A, |
| 1006TG2A,1006TAG | |
| Cooling Method | water cooled |
| Rated speed | 1500/1800 rpm |
| Intake type | Natural or turbocharged |
| speed governor | electrical or mechanical |
| Starting method | 12/24V DC electric starting |
| Stroke | 4 stroke |
| The brushless alternator of Lovol generator manual: | |
| Compliance with GB755,BS5000,VDE0530,NEMA MG1-22,IEC-34,CSA C22-100and AS1359 standards | |
| Brand | Stamford,marathon, leroy somer,Chinese brand,etc. |
| Excitation type | brushless |
| Number of Bearing | 1 |
| Rated current | 14.4-1800A |
| Insulation class | H |
| Protection class | IP23 |
| Voltage regulator | AVR |
| Control system of Lovol generator manual: | |
| 1)Control box with Ammeter,Voltmeter,Frequency Meter,Water temperature,Oil Pressure ,Hour counter,Phase TransferSwitch, CircuiBreaker,Indicator Light for power, generating & emergency. protection system with module for over speed,high temperature,low oli pressure. | |
| 2)LED contorl panel
|
|
| Output Power | Engine Model | Overall Dimensions | Weight(Kg) |
| (kW/kVA) | L * W * H mm | ||
| 19/24 | 404D-22TG | 1500*1000*1150 | 656 |
| 24/30 | 1003A-33G | 1500*1000*1150 | 656 |
| 35/44 | 1003C-33TG3 | 2070*1000*1240 | 840 |
| 40/50 | 1004C-44TG2 | 2070*1000*1280 | 895 |
| 52/65 | 1004C-44TG | 2070*1000*1280 | 944 |
| 62/78 | 1004TG | 2070*1000*1280 | 964 |
| 80/100 | 1006TG1A | 2500*1000*1420 | 1244 |
| 88/110 | 1006TG2A | 2500*1000*1420 | 1246 |
| 120/150 | 1006TGA | 2500*1000*1500 | 1458 |
| 140/175 | 1306C-TG2 | 2950*1300*1665 | 1912 |
| 176/220 | 1306C-TAG | 2950*1300*1665 | 2009 |
| 200/250 | 1306C-TAG1 | 2950*1300*1665 | 2193 |
| 220/275 | 1306C-TAG3 | 2950*1300*1760 | 2393 |
| 264/330 | 2006TWG2 | 2950*1300*1850 | 2896 |
| 304/380 | 2006TAG2 | 2950*1300*2010 | 3120 |
| 340/425 | 2006TTAG | 3300*1406*1860 | 3944 |
| 400/500 | 3008TAG3A | 3300*1406*1860 | 4120 |
| 440/550 | 3008TAG4 | 3500*1406*2000 | 4233 |
| 484/605 | 3012TG | 3500*1406*2000 | 4500 |
| 500/625 | 3012TWG2 | 3500*1406*2000 | 4500 |
| 572/715 | 3012TAG2B | 3680*1406*2000 | 4233 |
| 600/750 | 3012TAG2A | 3680*1406*2000 | 4233 |
| 704/880 | 3012TAG3A | 3680*1406*2000 | 5540 |
| 749/930 | 4008TAG | 4860*1880*2417 | 7625 |
| 800/1000 | 4008TAG1 | 4860*1880*2417 | 7625 |
| 880/1100 | 4008TAG2 | 4860*1880*2417 | 7625 |
| 1100/1375 | 4012TWG2 | 5374*1760*2462 | 10650 |
| 1120/1400 | 4012TAG | 5374*1760*2462 | 10650 |
| 1200/1500 | 4012TAG1 | 5250*2220*2895 | 10650 |
| 1320/1650 | 4012TAG2 | 5250*2220*2895 | 10650 |
| 1500/1875 | 4016TWG2 | 5760*2524*3100 | 12600 |
| 1540/1925 | 4016TAG | 5760*2524*3100 | 12600 |
| 1600/2000 | 4016TAG1 | 5760*2524*3151 | 12600 |
| 1760/2200 | 4016TAG2 | 5760*2524*3151 | 12600
|
1) Deutz 413,513 series engine, Deutz 912.913 series engine, Deutz 1012,1013,1015 ,2012 series
2) Deutz D302 series ,TBD226 series,TBD 234 series, TBD 600 series, TBG 600 series
3) MTU 396TB series, 396SE Series 396TC/TB/TE series ,956 series
4) IVECO Cursor 9,NEF6, F1C engine
5) VM R425 DOHC,VM R428 DOHC,VM D704/D754 Series motor
6) scdc M11,NT/NTA-855, KT/KTA/KTTA19,KT/KTA38, KTA/KTTA50, 4BT,6BT, C serials engine
7) engine spare parts
8) QD32T/TI engine
9) 4JA1,4BD1,6BD1
10) Lovol 1004 series and 1006 series
11) Pielstick PC2.2, 2.3, 2.4, 2.5, 2.6 PA6L-280,
12) Doosan P086TI and P086TI-1
13) GM6.5 engine
