Brand New 80KW /100KVA Marine Generator With 6BT5.9-GM100 Engine

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Business Type:

Manufacturer

Year Established:

2018

Factory Size:

Below 1,000 square meters

Contact Supplier Request Quote Chat Now

Jingjiang Fuji Technology Co., Ltd.

4Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

1,GENERAL RATINGS

Voltage	HZ	Phases&Wires	P.F(COS)	Rated Current (Amps)	Standby Ratings (KW/KVA)	Prime Ratings (KW/KVA)
400/230	50	3&3	0.8	144	88/110	80/100

Remarks: we can meet up other special voltage requirements

2,MARINE DIESEL ENGINE DATA

Engine Brand	SCDC
Engine Model	6BT5.9-GM100, 4 Stroke, Water Cooled.
Number of Cylinders	6 cylinders in line
Aspiration	Turbocharged and After-cooled
Bore×Stroke	102 x120 mm
Rated Speed	1500 RPM
Displacement	5.9 L
Prime Power	100KW /134HP
Speed Governor	Electrical
Cooling System	By heat exchanger
Fuel Consumption at 100% Load	213 g/kw.h
Starter Motor	DC24V

3,ALTERNATOR SPECIFICATION

Alternator Brand	Marathon, Siemens, Stamford, Sunvim or Equal
Alternator Model	MP-H-90-4
Power Capacity	90KW/113KVA
Frequency/speed	50HZ/1500rpm
Exciter type	Brushless, Self-excited
Power factor	0.8
Insulation Grade	H
Protection Grade	IP23(IP44 is optional)
Phase / wire	3 phase 3 wires

4,STANDARD CONTROL PANEL

*engine start/stop
*engine coolant temperature
*oil pressure and temperature
*tachometer
*coolant temperature alarm
*oil pressure alarm
*battery charging indicator
*generator to be protection from overload and overheat

5,STANDARD SUPPLY SCOPE

Complete standard open type marine diesel genset including engine, alternator, heat exchanger, sea water pump (for marine main power), Radiator (for marine main power genset or special requirements for marine emergency power genset), silencer, muffler, standard control system, user books, CCS certificates and other accessories.
