Weichai industrial power engine WP10 and WP12 series
WP10 and WP12 series engines are mature products which original from Austria Steyr diesel engine, and optimized and upgraded by R&D center of Weichai; WP13 is the new platform product which jointly developed by European R&D center and AVL. The power products of generation transmit the advantages of high reliability of this series engine, and focus on the using features and configuration requirements of land-based diesel generation power; have special optimized design with new design concept, and form the latest matched power for 150kW -400kW gen-sets.
The engine is frame engine body structure and single cylinder head, has the characteristics of advanced performance, high reliability, energy saving and environment protect, low noise and easy to start.
All series adopts down-turn supercharger, compact structure, simple and smooth, easy to install and transport.
All series adopts three level “nanny” filter, fuel is much cleaner, protect fuel injector and high pressure oil pump more effectively, and prolong the use life.
All series adopts high pressure oil pump connected by flange to improve connecting strength of oil pump, and reduce vibration problem caused by connection of coupling, improve reliability and reduce noise.
Meet qualifications of CCS, ZY, BV and RS; take the leading in same industry to pass ISO9001 quality system and GJB9001A-2001 military standard certification.
|
Engine Model |
WP10 |
WP12 |
WP13 |
|
Cylinder No. |
L6 |
L6 |
L6 |
|
Bore/Stroke(mm/mm) |
126/130 |
126/155 |
127/165 |
|
Displacement(L) |
9.726 |
11.596 |
12.54 |
|
Power range(kW) |
200-264 |
317 |
385-442 |
|
Rate speed range(r/min) |
1500/1800 |
||
|
Lowest fuel consumption(g/kW·h) |
≤195 |
≤195 |
≤195 |
|
Emission |
IMO tierⅡ |
||
