Wet Friction Materials Paper Sheets

Zhejiang Gaocheng Autoparts Co., Ltd

US$ 15 - 25 MOQ: 100 Kilograms

Key Specifications

Place of Origin:

China

Model Number:

Wet friction paper

Material:

Aramid fibres, Carbon fibres, Composite reinforced fibres

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai&Ningbo

Delivery Detail:

7 days

Place of Origin China

Model Number Wet friction paper

Material Aramid fibres, Carbon fibres, Composite reinforced fibres

Type Brake Discs

Size 600x1600x0.6-2.5mm

Certification ISO 9001:2015

Material:	Wet paper-based friction materials& Wet paper-based friction disc
Raw material (component):	45-55% fibre (aramid fibre, carbon fibre,composite reinforced fibre, etc.); 20% functional raw materials; remaining filling material (Aluminium oxide, silicone soil, color mixing materials, etc); After the paper is dipped in glue, the glue content is of 23-30%.
Size:	Paper width from the automatic paper production line: 600mm Diameter range <=1600mm, Paper thickness: 0.6~2.5mm
Industrial Standard:	GB/T 13826-2008 Wet type (non-metallic) friction materials GB/T 21955-2008 Tractor and machinery for agriculture and forestry --Paper friction disc-- Technical specifications GB/T 37208-2018 Nonmetallic paper based wet type friction materials GB/T 15141-2009 Test method for friction element of wet clutch
Applications range:	Engineering machinery: Excavator, Loader, Bulldozer, Paver, Reach stracker, Crane etc. Agricultural and forestry machinery: Tractor, Harvester and corresponding equipments Logistic machinery: Forklift truck, Port logistic machinery Automobile industrial machinery: Reducer, Wet cluth and Wet brake, Motorcycle clutch.
OEM and aftermarket	all types of wet paper-based friction disc, such as for Caterpillar, Komatsu, JCB, MF etc.

Specifications of wet paper-based friction materials
Application range	Specific pressure Mpa	Rotational speed m/s	Oil temperatur °C	Dynamic friction coefficient U_d	Static friction coefficient U_s	Wear rate (x10^-8cm³/J)
Motorcycle	0.2-0.5	15	≦120	≧0.16	≧0.20	≦6
Automobile	0.8-1.5	15	≦120	≧0.13	≧0.15	≦3
Engineering machinery	1.0-3.0	25	≦120	≧0.11	≧0.13	≦5
