Home > Transportation > Elevator & Funicular Car > Parts for Elevator & Funicular Car > Torin Elevator Motor Elevator Gearless Traction Machine

Torin Elevator Motor Elevator Gearless Traction Machine

Torin Elevator Motor Elevator Gearless Traction Machine thumbnail-3

Torin Elevator Motor Elevator Gearless Traction Machine thumbnail-4

Torin Elevator Motor Elevator Gearless Traction Machine thumbnail-5

Torin Elevator Motor Elevator Gearless Traction Machine photo-1

Torin Elevator Motor Elevator Gearless Traction Machine photo-2

Torin Elevator Motor Elevator Gearless Traction Machine photo-3

Torin Elevator Motor Elevator Gearless Traction Machine photo-4

Torin Elevator Motor Elevator Gearless Traction Machine photo-5

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Business Type:

Manufacturer

Year Established:

2018

Factory Size:

Below 1,000 square meters

Contact Supplier Request Quote Chat Now

Jingjiang Fuji Technology Co., Ltd.

4Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Product Description

Using the permanent magnet synchronous gearless traction machine as the power source, it is small in size and compact in structure, which can meet the design requirements of small machine room and provide more free design space for architectural design.

Name	Elevator Gearless Traction Machine
Voltage	380V
Speed(m/s)	1 - 2.5
Roping	2:1
Weight	350kg
Max. Shaft Load	3000kg
Brake	DC110V 2×0.88A

Details Images

Model	Load (Kg)	Speed (m/s)	Sheave Diam (mm)	Rope Sheave (mm)	Current (A)	Torque (Nm)	Rated Speed (rpm)	Frequency (Hz)	Power (kW)
NV41T-W7	630	1	Φ400	4×Φ10×16	9.7	420	96	25.6	4.2
NV41T-W7	630	1.5	Φ400	4×Φ10×16	14.9	420	144	38.4	6.3
NV41T-W7	630	1.6	Φ400	4×Φ10×16	14.9	420	153	40.8	6.7
NV41T-W7	630	1.75	Φ400	4×Φ10×16	15.9	420	167	44.5	7.3
NV41T-W7	630	2	Φ400	4×Φ10×16	18.3	420	192	51.2	8.4
NV41T-W7	800	1	Φ400	5×Φ10×16	12.1	530	96	25.6	5.3
NV41T-W7	800	1.5	Φ400	5×Φ10×16	18.8	530	144	38.4	8
NV41T-W7	800	1.6	Φ400	5×Φ10×16	18.8	530	153	40.8	8.5
NV41T-W7	800	1.75	Φ400	5×Φ10×16	20.7	530	167	44.5	9.3
NV41T-W7	800	2	Φ400	5×Φ10×16	23.2	530	192	51.2	10.7
NV41T-W7	1000	1	Φ400	5×Φ10×16	14.7	650	96	25.6	6.5
NV41T-W7	1000	1.5	Φ400	5×Φ10×16	22.9	650	144	38.4	9.8
NV41T-W7	1000	1.6	Φ400	5×Φ10×16	22.9	650	153	40.8	10.4
NV41T-W7	1000	1.75	Φ400	5×Φ10×16	25.1	650	167	44.5	11.4
NV41T-W7	1000	2	Φ400	5×Φ10×16	28.2	650	192	51.2	13.1

Different Models

Main Product Catalog

Company Profile

Exhibition

Product Packaging

FAQ

1. Price Re: please send us inquiry from , we will qutoe to you within 24 hours. It’s more convenient and appreciated for us if you provide your company details and your detail inquiry for elevators. 2. Payment term Re: T/T or L/C at sight. 3. Installation&Maintaining Re: We will send installation&maintaining manual along with the elevator. Our sugguestion is to hire a professional local company for installation and future maintaining, once you need any technical assistant from us, just don't hesitate to contact us by mail or phone. Technician will be sent to the job site if necessary. 4. Shipping&price term Re: Both FOB/CIF/CFR price term are ok, we have reliable forwarder helping arrange the shipment for you.
