ML45 Bimetal Defrost Thermostat Replacement Part PL009 ML45 12453 37T01 Good Price
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality 220v Defrost Timer TMDB TMDB-M8322X TMDB-M8322 TMDB-M8308 TMDB-M8429NegotiableMOQ: 1 -
TNM-01 Refrigerator Defrost Timer for Russian Market With Memorize FunctionNegotiableMOQ: 1
-
SANYKO TMDJ Defrost Timer WR9X483 WR09X0483 WR09X10075 833RC1 TMDJX35RB9NegotiableMOQ: 1
-
HVAC 10g 20g 25g 30g Refrigerator Copper Filter Drier 15gNegotiableMOQ: 1
-
Making Machine Copper Solder Filter Drier 15 Grams W/silica Freezer Refrigerator Copper Refrigerator Drier Filter CopperNegotiableMOQ: 1
Product Description
ltem NO |
PL009 ML45 (12453) |
Use |
Defrost/Temperature control/Protection |
Appliance |
refrigerators, freezer |
Reset type |
Automatic |
Base material |
bakelite |
Amperage |
3A/6A/10A/25A |
6Max. Operating Temperature |
60°C |
Differential |
According to the requirement |
Min. Diff |
8°C |
Tolerance |
Refer to the regulation |
Cold-resistant Temperature |
-30°C |
Limit of the tolerance(OFF) |
±3°C |
Limit of the tolerance(ON) |
±3°C |
Contact material |
Silver |
Dielectric Strength |
Parts between electriferous components and non-electriferous ones can bear 2000V (3750V for Reinforced insulation type) 50Hz AC current, which is nearly sine wave, for one minute as bearing test. Resulted no breakdown, no flashover. |
Insulation Resistance |
With a DC 500V megger, borne DC 500V, the tested value is over 10MW. |
Resistance Between Terminals |
Below 50mW |
Temperature characteristics |
Normal close, Normal open |
Maximum ambient temperature |
90°C |
Diameter of bimetal disc |
F12.8mm(1/2″) |
Line |
Color: white/brown/yellow/blue Length: customized |
Terminal type |
Customized (Refer to our specification) |
Cover/Bracket |
Customized (Refer to our specification) |
