1KW Small Air Cooled OHV 154f Gasoline Engine

Jingjiang Fuji Technology Co., Ltd.
4Yrs
1KW Small Air Cooled OHV 154f Gasoline Engine thumbnail-1
1KW Small Air Cooled OHV 154f Gasoline Engine thumbnail-2
1KW Small Air Cooled OHV 154f Gasoline Engine thumbnail-3
1KW Small Air Cooled OHV 154f Gasoline Engine thumbnail-4
1KW Small Air Cooled OHV 154f Gasoline Engine thumbnail-5
1KW Small Air Cooled OHV 154f Gasoline Engine photo-1
1KW Small Air Cooled OHV 154f Gasoline Engine photo-2
1KW Small Air Cooled OHV 154f Gasoline Engine photo-3
1KW Small Air Cooled OHV 154f Gasoline Engine photo-4
1KW Small Air Cooled OHV 154f Gasoline Engine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us



Company Information

1KW Small Air Cooled OHV 154f Gasoline Engine

Specifications

Gasoline engine
1. new technology, super silent
2. Big fuel tank,long run time
3. economic, reliable, durable



154f Gasoline Engine With 2-stroke Air Cooled OHV Structure



Product Description

  - Features

1. Portable compact open structure
2. Economical, reliable and durable
3. Long run time - up to 13.5 hours
4. Oil alert to shut down engine automatically when low oil is detected
5. CE, ISO certification approved
6. One year or 500 hours warranty

 1KW Small Air Cooled OHV 154f Gasoline Engine1KW Small Air Cooled OHV 154f Gasoline Engine1KW Small Air Cooled OHV 154f Gasoline Engine1KW Small Air Cooled OHV 154f Gasoline Engine1KW Small Air Cooled OHV 154f Gasoline Engine



Taizhou Bison Machinery Co.,ltd                            Gasoline Engine
Model BS90 BS160 BS200 BS210 BS270 BS390 BS420
Engine type BS154F BS168F BS168-1F BS170F BS177F BS188F BS190F
Bore x Stroke 154*38mm 168*45mm 168*52mm 170*52mm 177*58mm 188*64mm 190*64mm
Displacement 83cc 163cc 196cc 210cc 269cc 389cc 420cc

Compression

ratio

 7.7:1 8.5:1 8.5:1 8.5:1 8.2:1 8.0:1 8.0:1
Max out(HP) 2.6 5.5 6.5 7.0 9.0 13 15
Max out(KW) 2.0 4.1 4.9 5.3 6.8 9.6 11.3
Oil Capacity 0.37L 0.6L 0.6L 0.6L 1.1L 1.1L 1.1L
Fuel Capacity 1.6L 3.6L 3.6L 3.6L 6.0L 6.5L 6.5L

Min,Fuel

Consumption

( g-hp/H )

 450g 295g 280g 280g 280g 275g 275g

Dimensions

(LxWxH)

 300x290x280
390x330x350

510x400x

460

510x430x

475

510x430x

475
Net weight 10.6kg 15kg 16kg 17kg 28kg 33kg 34kg
Ignition system
non-contact transistorized ignition(TCI)
Starting System recoil and hand-operated
Air cleaner   semi-dry,oil bath,dual,double silent and cyclone type
Spark plug F6RTC F6RTC F7RTC F7RTC F7RTC F7RTC F7RTC

20FT Quantity

set

 630 630 630 630 268 268 268

40HQ Quantity

set

 1505 1505 1505 1505 652 652 652



Technology

Gasoline engine, with standard,mainly use for Gasoline Generator,Water Punp,Water Washer,Concrete Vibrators,Air-compressor,Welding machine!



Packaging & Shipping

  1KW Small Air Cooled OHV 154f Gasoline Engine1KW Small Air Cooled OHV 154f Gasoline Engine

Each gasoline engine is wrapped in poly bag, then into carton. With Owners Manual in it,Standard colorful carton is available, ready for retail.



Our Services

 1KW Small Air Cooled OHV 154f Gasoline Engine

 WE ARE PARTNER, WE ARE FAMILY

Taizhou BISONpeople are always paying great attentions to quality controlling from the beginning to the end. Every piece of goods is tested strictly one by one before packing.





FAQ

 1KW Small Air Cooled OHV 154f Gasoline Engine

 1.Q:Are you a factory or trading company?

A: We are a factory.

 2.Q:Where is your factory located?

A: Our factory is in Jiaojiang,Taizhou city, Zhejiang Province, China.

3.Q:What is the material of your products?

A: Iron,Steel,plastic,etc.

4.Q:How about quality control in your factory?

A:Taizhou Bisonpeople are always paying great attentions to quality controlling from the beginning to the end.

5.Q:How about guarantee?

A: It's within three months after goods is discharged in the destination.
