Displacement monitor module
The normal operation of structure is the basic requirement of building. The change of bearing capacity and environmental conditions has a great impact on the stability and security of structure. Therefore, accurate and reliable monitoring of structural displacement changes is the key to ensure engineering safety. The displacement monitor is the research result of detecting the displacement of the surrounding environment and its change rule, analyzing the state change of the structure and whether the monitoring method is reasonable. In general, the monitoring location is concentrated around the structure. The monitor generally has two forms: one is installed in the wall, used to monitor the wall displacement monitoring; The other is mounted on a bridge. The displacement monitor can realize the real-time monitoring of building deformation, and two kinds of results will be produced when measuring displacement: The displacement monitor module is to collect the displacement information in the building through the sensor and feed it back to the control center. The electromechanical equipment inside the house can be controlled remotely through the control switch, so that it is in good running condition.
I. Product overview
The displacement monitor is mainly composed of signal acquisition module, microprocessor and data processing platform, alarm system and control system, among which the signal acquisition module is mainly used to monitor the displacement change of the surrounding environment of the building. It is mainly used for the monitoring of pressure and temperature change, geocentric acceleration and orbit displacement in the building. The sensor is mainly used to measure displacement inside the house. The sensor can be installed in the wall to monitor the displacement of the wall and support; It can also be installed on the bridge to measure the displacement of the bridge. The characteristics of the displacement monitoring module are: • there are many kinds of sensors (currently in use: laser displacement monitor and ultrasonic displacement equipment); • With wireless transmission function; • In the process of signal transmission does not affect the internal ventilation of the house; • Sensors work automatically when the house is in working condition; • Adopt industrial-grade chip technology (IP68); • Can be directly connected to the mobile phone for remote operation, can be directly through the remote reception signal to achieve online control of the internal mechanical and electrical equipment in the house.
2. Product advantages
1. Fast response: real-time transmission speed of monitoring data is fast and data processing time is short. 2. Not affected by construction: no environmental interference, not easy to change the displacement affected by climate. 3. Can be installed around the building and equipment room: can be arbitrarily installed in the building wall, floor, roof and stairwell and other parts and arranged in the building. It can realize automatic lifting adjustment and control. 4. Easy installation: Just install the displacement monitor inside the building structure to complete the monitoring. At the same time can be adjusted and closed according to user requirements; Monitoring parameters can also be changed according to the actual situation. 5. Data collection mode: Supported collection modes include: wired, wireless, Bluetooth, LAN and other communication modes and monitoring modes can be selected according to site conditions. 6. Easy maintenance: can be installed inside the equipment, can not need special protection measures.
Three, product use
According to the different application, the use of different monitoring equipment to monitor the building, structural status monitoring, etc. Building components and structures in use will produce displacement, vibration, tilt, cracking and other phenomena, these are the structure produced or caused by the safety problems, and among these safety problems, the most prominent is the displacement problem. Therefore, it is very important to monitor the structure itself and the use condition of the structure. The displacement information around the building is collected by the displacement monitor and fed back to the control center for analysis and judgment before corresponding management. It can monitor and analyze the change of movement and displacement of the building structure in real time, so as to provide security for the structure.
------------------------------------------------------------------------------------------------------------------------------
Xiamen Xiongba Electronic Commerce Co. LTD
FROM：Mr. Wei
E-Mail：2322181769@qq.com
TEL/WeChat:15396237607
Bentley 3500 system is used for vibration monitoring and protection of large machinery. Bentley 3500 system must be equipped with frame 3500/05, power 3500/15, frame interface module 3500/22m,
bently3500 Bentley power high voltage AC 220V, spare parts as follows
127610-01 AC power module
125840-01 High-Voltage AC Power Input Module (PIM)
125840-02 Low-Voltage AC Power Input Module (PIM)
129486-01 High voltage DC power module
129478-01 High Voltage DC Power Input Module (PIM)
133292-01 Low voltage DC power module
133300-01 Low Voltage DC Power Input Module (PIM)
Spare fuse (two types of AC PIM and HVDC PIM)
01720045 Spare Fuse (Low voltage DC PIM)
129677-01 Power Operation and Maintenance manual
The order information and model of Bentley power supply bently 3500/15 are as follows:
3500/15-AXX-BXX-CXX option description
A: Power supply type (upper notch)
Low voltage AC (85-132 Vac rms)
02 High Voltage AC (175-264 Vac rms)
High voltage direct current (88-140 Vdc)
Low voltage DC (20-30 Vdc)
05 Universal AC Power Supply (85-264 Vac rms) (New)
B: Power supply type (lower notch)
No power supply (only used if single power supply is required)
Low voltage AC (85-132 Vac rms)
02 High Voltage AC (175-264 Vac rms)
High voltage direct current (88-140 Vdc)
Low voltage DC (20-30 Vdc)
05 Universal AC Power Supply (85-264 Vac rms) (New)
C: Approve the unit option
00 without
01 CSA/NRTL/C
02 ATEX/IECEx/CSA (Class 1, Zone 2)
CN China
Specific models are as follows:
3500/15 (front panel 127610-01, rear panel 125840-01)
3500/15-02-02-00, upper notch and lower notch are installed, so dual power supply,
3500/15-02-00-00, upper notch is installed, lower notch is not installed, so it is a single power supply
3500/15-05-05-00, upper notch and lower notch are installed, so it is dual power supply
The following is the upgraded 3500/15 universal AC power module:
3500/15(106M1079-01 front panel, 106M1081-01 rear panel)
3500/15-05-05-00, upper notch and lower notch are installed, so it is a set of double power supply
3500/15-05-00-00, upper notch is installed, lower notch is not installed, so it is a set of single power supply
If you need to inquire or purchase ,please send the product models to my email or call me directly .
Contact detail:Mobile/ WeChat/ WhatsApp:+86-15396237607
E-mail:2322181769@qq.com
QQ: 2322181769
