6 Inch PVC Fabric reinforced vinyl coated Blower Duct spring steel helix Collapsible Flexible Ventilation Air Duct

Name: 6 Inch PVC Fabric reinforced vinyl coated Blower Duct spring steel helix Collapsible Flexible Ventilation Air Duct
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Product Name	Flexible Duct
Material	Vinyl Coated Polyester VCP - High Tenacity Strength, 0.28mm - 0.6mm
Color	Orange, Yellow, Gray, White, Blue, Red, Black, Green,etc.(Customized)
Standard	Fire Retardant - B1, NFPA 701 certified
Shape	Cylinder Tube - Single, Twin, Tripple, Y-TYPE, T-TYPE, Braches-TYPE
Diameter	Ø4'',Ø6'',Ø8'',Ø10'',Ø12'',Ø14'',Ø16'',Ø18'',Ø20'',Ø22'',Ø26'',Ø28'',Ø30'',Ø60'', etc. (Customized)
Length	5m / 7.6M/ 10m / 20m/ 30m (Customized)
LAB	Self-Laboratory in house to test strength, water tightness, water pressure, etc
Temperature	-30℃ to+ 120℃
Compression Ratio	10:1
Accessories	D-Ring, Rope & Loop, Belted Cuff, Screw/ Bridge Clamps, Hanging Hook,
Used	Air / Gas Ventilations
Certification	ISO9001, ISO 14001, SGS, CTI, ROHS, CE
HS Code	39232900

Flexible Duct

Ideal use for permanent and mobile air conditioning units.

3-layer yellow polyester reinforced PVC vinyl fabric hose construction with an external wearstrip reinforced with a spring
steel wire helix • Lightweight duct for blower applications • Highly compressible • Retractability allows for convenient storage
and easy transport in a fraction of its fully extended length • Low friction loss • Wearstrip offers external abrasion resistance
• Listed as UL 94 V-0 flame retardant

Article	Diameter (Inch/cm)	Lengths (ft/m)	G.W. (lbs/kg)	Packing Size (Inch/mm)
DGFD-0805	8" / 20	16.4ft / 5m	7.7 lbs / 3.5kg	9.8x9.8x8.7/25x25x22
DGFD-0810	8" / 20	32.8ft / 10m	14.2 lbs / 6.5kg	9.8x9.8x14.9/25x25x38
DGFD-1005	10" / 25	16.4ft / 5m	9.9 lbs / 4.5kg	11.8x11.8x9.0/30x30x23
DGFD-1010	10" / 25	32.8ft / 10m	17.6 lbs / 8.0kg	11.8x11.8x14.1/30x30x36
DGFD-1205	12" / 30	16.4ft / 5m	11 lbs / 5.0kg	13.7x13.7x8.7/35x35x22
DGFD-1210	12" / 30	32.8ft / 10m	19.36 lbs / 8.8kg	13.7x13.7x13.7/35x35x35
DGFD-1405	14" / 35	16.4ft / 5m	13.2lbs / 6.0kg	15.7x15.7x8.7/40x40x22
DGFD-1410	14" / 35	32.8ft / 10m	27.06 lbs / 12.3kg	15.7x15.7x14.9/40x40x38
DGFD-1605	16" / 40	16.4ft / 5m	16.5 lbs / 7.5kg	17.7x17.7x8.7/45x45x22
DGFD-1610	16" / 40	32.8ft / 10m	31.9 lbs / 14.5kg	17.7x17.7x12.9/45x45x33
DGFD-1805	18" / 45	16.4ft / 5m	19.8lbs / 9.0kg	19.6x19.6x8.7/50x50x22
DGFD-1810	18" / 45	32.8ft / 10m	36.3 lbs / 16.5kg	19.6x19.6x13.7/50x50x35
DGFD-2005	20" / 50	16.4ft / 5m	23.1lbs / 10.5kg	21.6x21.6x8.7/55x55x22
DGFD-2010	20" / 50	32.8ft / 10m	37.84 lbs / 17.2kg	21.6x21.6x13.3/55x55x34
DGFD-2405	24" / 60	16.4ft / 5m	24.64 lbs / 11.2kg	25.9x25.9x7.87/66x66x20
DGFD-2410	24" / 60	32.8ft / 10m	27.5 lbs / 12.5kg	25.9x25.9x12.5/66x66x32

Products Show

1. 3-layer Corrugated Carton Box

2. Pallet

3. Pallet With Carton Box

4. Steel Lockable Storage Cage

5. Polywood Box

6. Complete package

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
