Help CenterFURUNO FE800 Color IMO Navigation Echo Sounder
Related Products
FURUNO FE800
Display the clearance below the ship
The FE800 is a result of Furuno's many decades of experience developing echo sounders, sonars, and underwater application equipment and systems. This echo sounder is a breakthrough over the conventional paper sounders; there are no consumable items. The purpose of the echo sounder is to provide safe navigation by detecting the clearance below the ship (particularly in shallow waters) as required on the SOLAS Convention ships by the new IMO standards. The basic system consists of a display unit and distribution box. The 8.4" high-brightness color LCD display offers an easy-to-read depth sounding in various modes, permitting optimum representation with respect to the environment.
The FE800 generates alerts when the water depth below the transducer is shallower than the preset depth. When the seabed is lost due to the lowered power supply or out of range scale, an alert is generated. The receiver sensitivity is automatically controlled with the tracking depth; manual override is possible to improve the detection and to reduce the surface clutter.
Providing mission critical data at your fingertips
Own Ship Data
View your Own Ship Data (OS Data) when the FE800 is connected to an external GPS Navigator.
History
Display a combination of Contour and Strata echo readings in preset intervals of 5 seconds, 1 minute or 2 minutes.
Logbook
Display the stored time, depth and own ship position. The logbook is capable of storing data for up to 720 log entries.
Alert Log List
Displays up to 100 alerts stored in history.
Please send email to us for more details:
sales@malinsmarine.com
Product Introduction
Malins Marine Service Co.,Ltd.
Was established in 2010 as a wholesaler and service provider of marine navigation & communication equipment.During the past years, the company has expanded by several folds in terms of size as well as business turnover.
The company started up in 2010 with one office and two persons and now has three offices and one warehouse, with working team of over 20 persons.As China continues to develop, Malins Marine is in a strong position not only to utilize the resources available domestically but also to introduce foreign shipyards and marine prodcuts to the ship owners and ship managers of China. Malins Marine collaborates closely with worldwide leading and specialized maritime equipment suppliers and manufacturers in order to provide our wide range of clients a full breadth of products and genuine spare parts as well.
With the support of a global network of well-known manufacturers, we are able to meet the growing & challenging demands of our customers from a sustainable development perspective.One-stop service for spare parts supplied and service, provide economic solution for ship owners & managers. To fully meet our customers’ requirements, we also specialise in navigation and communication systems, statutory annual radio surveys, annual performance tests as well as after-sales services. Our comprehensive line includes high quality electronics for navigation, communications, and safety & security applications. Over the years, we have built our service net covered China Coastal Port from north to south. Most of attending engineer trained by major makers and we owned genuine spare parts of kinds of makers in Shanghai head office.
Sales & Service
Sales navigation & communication equipment & spare parts
Service: installation/commission/repairing/calibration
Furuno, JRC, Sailor (Thrane&Thrane)- Cobham, Yokogawa, Tokimec (Tokyo Keiki), Raytheon Anschutz, Sperry, SAM Electronics, L3, Kelvin-Hughes, Mcmurdo, Jotron, Danelec, Samyung, Highlander, Headway, Rutter, Netwave, Simrad, JMC, Taiyo, STN Atlas, Cassens & Plath, C-plath, Teledyne, Consilium, Kongsberg, Samsung....
One-Stop Solutions, We care.
