Help CenterModel EB2500 Magnetic Bending Machine
Related Products
-
Universal Bender Machine UB-100A With High QuantityNegotiableMOQ: 1 -
EB625 625 1.6mm Magnetic Steel Bending MachineNegotiableMOQ: 1
-
Sheet Metal Bending Machine EB1000 Metal Sheet Bending Machine With High QualityNegotiableMOQ: 1
-
Hand Notcher HN-3/102 With High QuantityNegotiableMOQ: 1
-
EB1250 Magnetic Bending Machine for Metal WorkingNegotiableMOQ: 1
Features:
1. Manual type with magnetic to clamp
2. Magnetic clamping brake
3. Easy raise clamping car.
4. Unlimited box depth.
5. Include multiple finger lengths.
6. Bending stop included.
Description:
The machine is very different from ordinary folders because it clamps the work piece with a powerful electro-magnet rather than by mechanical means. This leads to numerous advantages as following. It gives you much more freedom to make the shapes you want.
a) Much greater versatility than conventional sheet metal benders.
b) No limitation to depth of boxes.
c) Can form deep channels, and completely closed sections.
d) Automatic clamping and unclamping means faster operation, less fatigue.
e) Accurate and continuous indication of beam angle.
f) Quick and accurate setting of angle stop.
g) Unlimited throat depth.
h) Infinite length bending in stages is possible.
i) Open ended design allows folding of complex shapes.
j) Machines can be ganged end-to-end for long bending.
k) Adapts easily to customised tooling (clamp bars of special cross-sections).
l) Self-protecting - machine cannot be overloaded.
m) Neat, compact and modern design.
| Specification | Model EB2500 |
| Max .length×thickness | 2500×1.6mm |
| Clamping force | 12 ton |
| Duty cycle | 30% |
| Back gauge | 640mm |
| Foot switch | standard |
| Protection | Thermal cut-out 70°C |
| Nominal current | 15Amp |
| Bending -edge length | 2590 |
| Distance between lifters | 2528 |
| Packing size | 270×112×38cm |
| N.W/G.W | 330/420KG |
Standard clamping bars:
More pic. for machine:
