Factory price wholesale 1080P Measurement thermal attendance phone security access control face recognition camera system
Features:
- Non-contact automatic body temperature detection, brush human face and perform high-precision infrared human temperature acquisition at the same time, fast and high effect
- Temperature measurement range 30-45 (℃) Accuracy ±0.3 (℃)
- Automatically identify unmasked personnel and provide real-time warning
- Support temperature data SDK and HTTP protocol docking
- Automatically register and record information, avoid manual operation, improve efficiency and reduce missing information
- Support mid-range temperature measurement and real-time warning of high temperature
- Support binocular live detection
- Unique face recognition algorithm to accurately recognize faces, face recognition time <500ms
- Support human motion tracking exposure in strong backlight environment, support machine vision optical wide dynamic ≥80dB
- Adopt Linux operating system for better system stability
- Rich interface protocols, support SDK and HTTP protocols under multiple platforms such as Windows / Linux
- 7-inch IPS HD display
- IP34 rated dust and water resistant
- MTBF> 50000 H
- Support 22400 face comparison library and 100,000 face recognition records
- Support one Wiegand input or Wiegand output
- Supports fog through, 3D noise reduction, strong light suppression, electronic image stabilization, and has multiple white balance modes, suitable for various fields
Scene demand
- Support electronic voice broadcast (normal human body temperature or super high alarm, face recognition verification results)
Specification:
|
Model |
KDM-FT8203E |
|
Hardware |
|
|
Chipset |
Hi3516DV300 |
|
System |
Linux operation system |
|
RAM |
16G EMMC |
|
Image sensor |
1/2.7" CMOS |
|
Lens |
4mm |
|
Camera Parameters |
|
|
Camera |
Binocular camera supports live detection |
|
Effective pixel |
2Mega pixel,1920*1080 |
|
Min. lux |
Color 0.01Lux @F1.2(ICR);B/W 0.001Lux @F1.2 |
|
SNR |
≥50db(AGC OFF) |
|
WDR |
≥80db |
|
Face Recognition |
|
|
Height |
1.2-2.2 M, angle adjustable |
|
Distance |
0.5-3 Meters |
|
View angle |
Vertical ±30 degree |
|
Reco. Time |
<500ms |
|
Temperature |
|
|
Range |
30-45(℃) |
|
Accuracy |
±0.3(℃) |
|
Distance |
0.3-0.8m |
|
Response time |
<300ms |
|
Interface |
|
|
Internet interface |
RJ45 10M/100M Ethernet |
|
Weigand port |
Support input/output 26 and 34 |
|
Alarm output |
1channel relay output |
|
USB port |
1USB port (Can be connected to ID identifier) |
|
General |
|
|
Power input |
DC 12V/3A |
|
Power consumption |
20W(MAX) |
|
Working temperature |
10℃ ~ +50℃ |
|
Humidity |
5~90%, no condense |
|
Dimension |
123.5(W) * 84(H) *361.3(L)mm |
|
Weight |
2.1 kg |
|
Column aperture |
33mm |
Please click here to contact us for more protective products
1.Packaging: The actual weight depends on the final package,and the package may be changed, it can be negotiated.
2.Shipping: Shipping by air, Except Iran, other countries and regions can basically transport.
DELIVERY TIME: 7 days
Quality warranty: 1 year
Delivery port: Shenzhen port , China
Weight: 1.9KG
Dimension: 123.5(W) * 45.5(H) *266(L)mm
Delivery type: DHL, FEDEX, UPS
