Home > Products > Tapered roller bearing > 7707A 6-7707 U 7707 2101-2403036 Rear Axle Front Axle Bearing for VAZ-2121 VAZ-21213 VAZ-2123
7707A 6-7707 U 7707 2101-2403036 Rear Axle Front Axle Bearing for VAZ-2121 VAZ-21213 VAZ-2123
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
6-57707Ay Double Row Tapered Roller Bearing 350307X2D Size 35x80x57 for VAZ GAZ Car a Low Price in Stock
-
6-127509AK 32209 Roller Angular Contact Bearing With Tapered Roller 3151-3103025 Size 45*85*24.75 for UAZ Car
-
Chinese Factory Profession Single Row 27606 27606a 6-27606a 32306b Tapered Roller Bearings
-
Tapered Roller Bearing LM68149/LM68111 Kit Size 34.98x59.975x15.875 for Russia Cars a Low Price in Stock
-
2101-2402025-01 Bearings for Car Automobile Transport Cranes and Loaders Truck Crane Cranes and Loaders Loader Tractor
-
LM11749/45449 Kit Size 17.462x39.878x13.843 Tapered Roller Bearing Rear Wheel Bearing in Stock
Product Description
Specification
Product name | 7707A 6-7707 U 7707 2101-2403036 rear axle front axle bearing for VAZ-2121 VAZ-21213 VAZ-2123 |
Usage | Single-row Taper Roller Bearing |
Size | 33x62x16 |
Car Make | VAZ-2101 VAZ-2102 VAZ-2103 VAZ-2105 VAZ-2106 VAZ-2107 VAZ-21213 VAZ-2123 VAZ-2121 |
Place of Origin | China |
Brand Name | VLBG |
Model Number | 7707 OEM 2101-2403036 6-7707y |
Warranty | 24Months |
Inner diameter | 33MM |
Outside diameter | 62MM |
Height | 16MM |
Bearing type | Friction bearings |
Certificate | ISO9001/TS16949 |
Roller body material | SHX15 |
Weight | 0.211 kg |
Number of rolling bodies | 19 |
Standard | TU 37.006.170-90 |
Roller length | 11.04 |
Type of perceived loads | Radial thrust |
Roller Body diameter | 6.36 |
single-row tapered angular contact roller bearing 7707 2101-2403036
Angular contact roller bearing 7707designed for the simultaneous perception of axial and axial loads, which allows you to expand the scope of its application and significantly simplify the design of the supporting units of mechanisms and equipment. In application Angular contact roller bearing 7707 reduces the alignment requirements, which is very important in the production of products, especially large-sized ones. Mounting a single bearing provides the ability to take a radial load together with an axial load acting in one direction (paired installation, with axial bidirectional). Angular contact roller bearing 7707 has a wide range of applications: in general mechanical engineering equipment, in transmissions of tractor and automotive equipment, in wheel hubs, in metalworking machines.
Bearing 7707 (Niva bridge)
Tapered roller bearings, angular contact, single-row. A modification is made with a steel cage (letter Y to the right of the number) or polyamide (letter E is additionally indicated). If a bearing with a polyamide cage is damaged, it is less likely to damage other parts of the car than with a steel one. Contact angle from 10 to 18 °.
In Russia, this type is manufactured at the Volzhsky Bearing Plant (formerly 15 GPPs, products are now labeled VPZ). and also at the Samara Bearing Plant - 9 GPPs.
Bearing 7707, along with bearing 7705, is intended for use only in VAZ cars - "classic" (models 2101, 2102, 2103, 2104, 2105, 2106, 2107) (rear axle) and Niva 2121 4x4 (front and rear axles, differential box) ... Here they are installed in pairs. Another unit where this type is installed is the VAZ 1111 "Oka" differential.
This standard size does not have an exact foreign analogue.
Technical characteristics of the bearing 7707
Inner diameter - 33 mm;
Outside diameter - 62 mm;
Width - 16 mm;
Weight - 0.211 kg;
Number of rollers - 19 pcs.;
Roller dimensions - 6.36 / 7.0x11.04 mm;
Dynamic lifting capacity - 76 kN;
Static lifting capacity - 82 kN;
The maximum rated speed is 6300 rpm.
6-7707 U Rear axle bearings for VAZ-2101 VAZ-2102 VAZ-2103 VAZ-2105 VAZ-2106 VAZ-2107 car Passenger car
7707 Mechanical Equipment Parts Tapered Roller Bearings Sizes
7707(30607）OEM 2101-2403036 6-7707y for Russian VAZ car
Truck mounted cranes tapered roller bearing 6- 7707 y OEM 2101-2403036
7707 Reliable Quality Single-row Taper Roller Bearing 30607 For Rolling Mill Size
7707 2101-2403036 bearings for Car Automobile transport , Cranes and Loaders Truck Crane,Cranes and Loaders Loader, Tractor.
6-7707 U Rear axle bearings for VAZ-2101 VAZ-2102 VAZ-2103 VAZ-2105 VAZ-2106 VAZ-2107 car Passenger car
7707A 6-7707 U rear axle front axle bearing for Off-road cars VAZ-2121
7707A 6-7707 U Rear axle, differential Front axle, differential for VAZ-21213 VAZ-2123
Bearing 7707 of the LADA 2101 rear axle reducer side (differential) (roller tapered) 2101-2403036
