Multipack Pipe Fire Compression Cone Roll Wood Wire Pillow Wrap Aluminium Profile Pack Machine For Sew Thread
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1992
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cone Pillow Compression Roll Wrap Pipe Multipack Fire Wood Wire Aluminium Profile Pack Machine For Sew ThreadNegotiableMOQ: 1 -
1Kg Individual Manual Mini Small Salt Flow Caramel Wrap Wrapper Spice Pack Machine Powder For SaltNegotiableMOQ: 1
-
Individual Caramel 1Kg Salt Small Manual Wrapper Flow Mini Wrap Spice Pack Machine Powder For SaltNegotiableMOQ: 1
-
Automatic Horizontal Kitchen Clean Mini Sponge Tableware Very Speed Pillow Type Flow Wrapper Chopstick Pack MachineNegotiableMOQ: 1
-
Clean Kitchen Sponge Horizontal Wrapper Very Speed Automatic Tableware Pillow Type Mini Flow Chopstick Pack MachineNegotiableMOQ: 1
Product Description
Application:
Applicable for packing various regular objects,such as biscuits, pie, chocolate, bread, instant noodle ice cream, moon cake, large packets of paper towels, sanitary napkins,hardware, paper boxes, plates, vegetables, etc.
Features:
1.Double transducer control, flexible bag length cutting, operator needn't to adjust the unloading working, saving time and saving films.
2. human-machine operation, convenient and quick parameter setting.
2. human-machine operation, convenient and quick parameter setting.
3.Self diagnosis failure function, clear failure display.
4. High sensitivity optical electric color mark tracking and digital input cut position which makes the sealing and cutting more accurate.
5. suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. All the controls are achieved by software, convenient for function adjusting and upgrading.
4. High sensitivity optical electric color mark tracking and digital input cut position which makes the sealing and cutting more accurate.
5. suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. All the controls are achieved by software, convenient for function adjusting and upgrading.
Product Paramenters
Paramater: | ||||||||||
Model | GD-250 | GD-320 | GD-350 | GD-450 | GD-600 | |||||
Width of the film | Max250mm | Max320mm | Max350mm | Max450mm | Max600mm | |||||
Length of the bag | 65-190/120-280 90-220mm | 5-190/120-280 90-220/150-330mm | 65-190/120-280 90-220/150-330mm | 130-450mm | 120-500mm | |||||
Width of the bag | 30-110mm | 50-160mm | 50-160mm | 50-180mm | 100-280mm | |||||
Products are highly | Max.40-55mm | Max.40-60mm | Max.40-60 | Max.75mm | Max.110mm | |||||
Roller diameter | Max.320mm | |||||||||
Packing speed | 40-230bag/min | 40-230bag/min | 40-230bag/min | 30-150bag/min | 20-150 bag/min | |||||
Power | 2.4kw | 2.6kw | 2.6kw | 3.2kw | 3.6kw | |||||
Size | 3770*670*1450 | 3770*720*1450 | 4020*770*1450 | 4020*820*1450 | 4020*920*1460 | |||||
Weight | 450kg | 500kg | 580kg | 650kg | 680kg | |||||
Optional configuration | code punching machine inflatable device cake falling machine material handling machine | |||||||||
Packaging materials | such as single heat seal BOPP/composite film; such as OPP comopsite PE PET composite PEE | |||||||||
Bag shape | back seal packaging(round hole and butterfly hole can be coustomized) | |||||||||
Trans | Mesh type sealing,stripe type sealing,knife edge serrated mouth, flat mouth plus V easy to tear | |||||||||
