KT-BJ/A type coating machine
USAGE:
1.This adhesive coating machine is suitable for making self-adhesive or coating adhesive sticker on the Kraft paper, trademark,advertising, double-sided tape, BOPP, masking Tape, PE, non-woven fabric, PU, EVA, foam, etc.
2. Widely applied in industries of shoes, handbag, bag and luggage, lighting, advertising, packaging, decoration and etc.
CHARACTERISTICS:
1. Fully - automatic tension control, fully - automatic temperature control, many coating die extruders are optional.
2. Winding and unwinding can be installed swing type replacement shaft, which can reduce the stop frequency and shorten stop time, work efficiency.
3. High accurate fine-tuning device to ensure the coating quantity precision.
TECHNICAL PARAMETERS:
Length of Oven: 4m~6m X 3 segments (customizable)
Standard of Laminating Roller: F800X1700mm
Standard of Coating Roller: F300X1700mm
Motive Power: 3HP+2HP+2HP
Primary Fan Power: 3HP~5HP/ 380V
Power of Circulating Fan and Exhaust Fan: 2HP~3HP/ 380V
Electric Heating Tube: 1.5KW X 54PCS = 81KW
Power: 380V+ 220V/ 100KW
Production Speed: 0~30m / min
Working Width: 1650mm (customizable)
Size(L×W×H)(mm): 18000~ 25000*2000*2600
APPLICATION:
ENGINEERS ONSITE SERVICE AVAILABLE:
