Hydraulic Automatic Cutting Machine

Hydraulic Automatic Cutting Machine photo-1
Hydraulic Automatic Cutting Machine photo-2
Hydraulic Automatic Cutting Machine photo-3
Hydraulic Automatic Cutting Machine photo-4
Hydraulic Automatic Cutting Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2016
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Hydraulic Automatic Cutting Machine

Health Care Medical Supplies Die Cutting Machine

Football Panel Die Cut Press



Product Description



  Hydraulic Automatic Cutting Machine

1. This type of die cutting machine with conveyor belt is used for continuous and large-batch cutting of nonmetal materials in rolls or in sheets, such as carpet and car interior materials, ball panel materials, leather, rubber, film, fabric and other materials.



2. The materials conveying part adopts PLC control. The materials are driven by servo motor and feed in from one side of the machine and finished products come out from the other side. The feeding is precise and automatic. The feeding length can be adjusted conveniently through touch screen.



3. The machine is installed with four-column guiding, double-crank balancing, four-column blocking fine-adjustment mechanism and specially designed hydraulic control system, providing high speed and precise cutting operation. Central oil supply automatic lubricating device reduces the abrasion of all movable connecting parts to the minimum extent.



4. The die cutter or cutting mould can be fastened by pneumatic clamp device so as to make its replacement convenient and prompt.



5. Machines with special specifications can be available on request.


Key Points:

Conveyor Belt: Germany or Switzerland Made or Customizable

Oil Pump: Germany Made or Customizable

Special Hydraulic System lowers the operation noise



Sealing Ring: Made in Italy
Press Switch: Made in Italy
Cutting Switch: Made in Germany

Hydraulic Automatic Cutting Machine

Hydraulic Automatic Cutting MachineHydraulic Automatic Cutting Machine

Hydraulic Automatic Cutting MachineHydraulic Automatic Cutting Machine

Hydraulic Automatic Cutting Machine Details:Hydraulic Automatic Cutting Machine

Hydraulic Automatic Cutting Machine Application:

Hydraulic Automatic Cutting Machine



Technical Specs (Customizable):



Maximum Cutting Force40T60T
Cutting Area (mm)1250*8001250*1200/1600*1200
Tension Distance (mm)25-13525-135
Motor Power4KW5.5KW
G.W50007500

 Hydraulic Automatic Cutting Machine



Packaging & Shipping

Hydraulic Automatic Cutting Machine

Inner Package: Protective Film, etc

Outside Package: Plywood Case

  • Machines well packed with protective film and loaded in plywood case or export container;
  • English version operation manual and technical data;
  • One-Year-Period wear parts;
  • Tool kit

Hydraulic Automatic Cutting Machine



Our Services

  Hydraulic Automatic Cutting Machine

Hydraulic Automatic Cutting Machine

Hydraulic Automatic Cutting MachineHydraulic Automatic Cutting MachineHydraulic Automatic Cutting Machine

Company Information

 Hydraulic Automatic Cutting Machine

Since 1985, we have been manufacturing various cutting machines for different industries, such as packaging industry, footwear industry, garment industry, etc. Strong engineering power and satisfactory aftersale service consolidates our leading place in both domestic market and overseas market.

Hydraulic Automatic Cutting Machine



Hydraulic Automatic Cutting Machine
