Car Door Lock Actuator for Aftermarket 12V / 24V 113mm Length
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
2001
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Car Door Locking Actuator High Quality Waterproof IP67 Tailgate Lock Actuator With Normal on Normal off Working StatusNegotiableMOQ: 1 -
Promata Double Unlock Function 12 V/24 V Car Central Locking System 4 Doors Central LockingNegotiableMOQ: 1
-
Promata High Quality Universal 2 Wired ODM Car Door Lock Actuator for 2/4 DoorNegotiableMOQ: 1
-
High Quality 2 Wires Car Central Lock Actuator DB801-4NegotiableMOQ: 1
-
Shortest Universal Central Locking System Remote Control Door Lock OA801-5NegotiableMOQ: 1
Product Description
Universal Car Actuator Motor
Application: 2 door / 3 door / 4 door Vehicle
Options: Single actuator / Actuator with hardware
Technical Specifications:
Technical Specifications:
Type |
Gear type |
Measurement (L×W×H) |
113×61.6×29.5 mm |
Voltage |
12V |
Stall current |
< 7A |
Output Force |
50 N |
Endurance |
50,000 cycles |
Stroke |
17±1mm |
Actuator head |
360° rotatable |
Water Resistance |
IPX3 |
Operational temperature |
-30°C to +75°C |
Material |
ABS |
Terminal |
Bullet terminal |
Note:
* The stroke optional range is 10mm to 18mm.
* The current voltage optional range is 12V / 24V / 36V / 48V.
* The current voltage optional range is 12V / 24V / 36V / 48V.
Motor direction: |
||
Green wire |
Blue wire |
|
Lock |
+ |
- |
Unlock |
- |
+ |
Company Profile
Sinotek co.,LTD is a manufacturer founded in 2001, has grown to become a trusted supplier of TPMS, Parking Sensor, Actuator, Central Locking System, Remote Control System, Window Closer, etc..
We sell our products to OE, OES and aftermarket in more than 30 countries.
We are an ISO9001/TS16949 certified factory occupied 20,000 square meters.
Our cooperation partner: Schrader, Steelmate, Audiowell, Toyota (Indonesia), Great wall Motor, Changan Automobile, Dongfeng Motor, etc. We work together with our partners to create value for consumers.
FAQ
Q1-Except wholesales, Can you retail 1-2 set?
Sure, it is available, and would ship to door by express via DHL, UPS, FEDEX, TNT.
Q2-Can LOGO my design and resell?
Sure, it is accept ODM to your country market.
Q3. How long is the lead time for sending sample ? Does the sample fee can be returned ?
Usually it will takes 2~5 days working days for sample preparing & sending.
Q4. Do you have stock?
We produce including order, with a few entire product in strock. For against market floating, our soluion is preparing material in advance.
Q5. Could you do development or OEM for me?
Yes, we are warmly welcome the developing requirement client. With our professional Engineer, we could do a lot for you on your project. Please contact us!
