Home > Products > Oil Chiller > CNC Machine Cooling Spindle Oil and Water 220V 380V Oil Chiller

CNC Machine Cooling Spindle Oil and Water 220V 380V Oil Chiller

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Model

QG-012LY

QG-015LY

QG-025LY

QG-035LY

QG-052LY

QG-080LY

QG-120LY

Item

Unit

Cooling Capacity

BTU/HR

4000

5200

9000

12000

18000

24000

36000

W/HR

1200

1500

2500

3500

5200

8400

12500

Power

435

535

885

1190

2600

3500

4500

Current

2.5

3.0

4.1

5.6

Voltage Frequency

V/Hz

3∮220V/50Hz 3∮380V/50Hz

Motor capacity

190

370

370/750

750

750/1500

Pump flow

L/min

3.7

4.2/7

6/10L

10L/20L

40/60

Temperature Accuracy

℃

±0.5

Pipe diameter of air outlet/inlet

inch

½"X ½"

¾"X ¾"

1"X 1"

Conditions of usage

Room temperature(℃)

0-50

Oil temperature(℃)

10-45

Oils

VG5#-VG15# cooling oil

VG5#-VG15# cooling oil VG68# anti-wear hydraulic oil

Dimensions

365x450x625

350x450x750

440x510x835

465x575x1000

620x590x1043

705x605x1050

1300x560x1110

Refrigerant

Type

R22

Control method

Capillary throttle

Company Profile

Wuxi Fagor Technology Co.,Ltd.is specialized in CNC machine tools accessories .The main products of our company are 4 axis rotary table,5 axis rotary table,water pump, chuck, coupling, end mill grinder,chipping machine,cutter barrel,three-color lamp,knife tower and other accessories With high precision and full varieties are deeply trusted and appreciated by customers.At the same time we have a strong sales team and experienced core service team.we are ready to provide CNC machine tool accessories one-stop solution for you,looking forward to cooperating with you and going to a win-win situation

FAQ

Q: How long is the quality guarantee?
A: One year guarantee.

Q: How long is the delivery time?
A: Generally it is 3-7 days if the goods are in stock. If the goods are not in stock, it will take 8-20 days.

Q: Do your products have a factory inspection before shipment?
A: 100% self-inspection before shipment.

Q: Can you provide some free samples?
A: Actually we have a very good price principle, when you make the bulk order then cost of sample will be return to you.

Q: What kind of packing do you send?
A: We use high quality cartons, internal environmental protection buffer material.

Q: What is our loading port?
A: Usually in Shanghai port, or apply for other ports.
