SLT Series Tool Turret Quick Change Lathe 8 12 Station Tool Holder 63mm 80mm 100mm Servo Turret

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Item	Unit	Model
Item	Unit			SLT63	SLT80	SLT100
Center height	mm	63	80	100
Allowed number of tools		8;12	8;12	8;12
Time for 45°ratation and clamping	sec.	0.23	0.35	0.42
Time for 180°ratation and clamping	sec.	0.55	0.76	0.83
Clamping force	kg	1700	2600	3500
Hydraulic working pressure	MPa	3.5±0.5	3.5±0.5	3.5±0.5
Flow rate	L/min	18	20	25
Indexing accuracy		±4"	±4"	±4"
Accuracy of repeatability		±1.6"	±1.6"	±1.6"
Net weight (Without tool disc)	kg	50	68	88

FAQ

Q: How long is the quality guarantee?

A: One year guarantee.

Q: How long is the delivery time?

A: Generally it is 3-7 days. If the goods are in stock. If the goods are not in stock, it will take 8-20 days.

Q: Do your products have a factory inspection before shipment?

A: 100% self-inspection before shipment.

Q: Can you provide some free samples?

A: Actually we have a very good price principle, when you make the bulk order then cost of sample will be return to you.

Q: What kind of packing do you send?

A: We use high quality cartons, internal environmental protection buffer material.

Q: What is our loading port?

A: Usually in Shanghai port, or apply for other ports.
