Home > Instruments & Meters > Test Instrument > Test Machine > Door Remote Control3 Button 433 92MHZ High Power Remote 1000m Remote Control
Door Remote Control3 Button 433 92MHZ High Power Remote 1000m Remote Control
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
1990
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
433 Mhz Rf Module Wireless Data Transmitter and Receiver 500m Max Power Time Dimensions Output Input Hours Origin Transfer RateNegotiableMOQ: 1 -
433 Mhz Rf Module Wireless Data Transmitter and Receiver 500m Max Power Time Dimensions Output Input Hours Origin Transfer RateNegotiableMOQ: 1
-
433mhz rf Module 3 Button 433 92MHZ High Power Remote 1000m Remote ControlNegotiableMOQ: 1
-
Remote Control Toys White Shell Learning Code/Fixed Code 15 Buttons 433 92MHZ DC12V Wireless RF Remote ControlNegotiableMOQ: 1
-
Remote Control Toys 4 Metal Shell Rolling Code 4 Buttons 433 92MHZ DC12V Black LED Light Auto Anti Frame Timer Shock ColorNegotiableMOQ: 1
Product Description
Remote control technical parameters
Working voltage: DC12V/23A
Working frequency: 315/433.92MHz±0.2MHz (other frequencies can be customized)
Working current: 34mA
Coding method:
fixed code (PT2262 chip) address code pad can be programmed with more than 5,000 sets of different codes
Learning code (eV1527) million sets of chips come with different ID address codes
Rolling Code (HCS301)
Transmission distance: >100m (the sensitivity of the receiving board in the open field is above -103dBm)
Output power: 16dBm (40mW)
Transmission rate: <10Kbps
Modulation method: OOK (amplitude modulation)
Working temperature: -10℃~+70℃
Size: 96×43×16mm
Multiple buttons are remotely selectable
2 buttons remote
2 buttons remote
Detailed Images
Remote control + a variety of applicable models of receiving module matching
4 button remote +5V fixed code receiving module
4 buttons remote +5V learning code receiving module
4 buttons remote +5V learning code (small size) receiving module
Introduction of product advantages or application effect or application mode
产品优点or使用效果or使用方式的介绍说明
1~4 key remote options
Working voltage: DC12V/23A
Working frequency: 315/433.92MHz±0.2MHz (other frequencies can be customized)
Coding method: fixed code (PT2262 chip) 8-bit address coding pad
Learning code (eV1527) million group ID address code
Transmission distance: >100m (the sensitivity of the receiving board in the open field is above -103dBm)
Size: 96×43×16mm
Multiple buttons are remotely selectable
Working voltage: DC3.3~5V
Working frequency: 433MHz (others can be customized)
Receive sensitivity: -108dB
Output: 4-channel CMOS level signal corresponding to the ABCD 4 button of the remote control.
Standard decoding program, learning type, compatible with PT2262/EV1527 chip remote control
5V learning code receiving module
Working voltage: DC3.3~5V
Working frequency: 433MHz (others can be customized)
Receive sensitivity: -108dB
Output: 4-channel CMOS level signal corresponding to the ABCD 4 button of the remote control.
Standard decoding program, learning type, compatible with PT2262/EV1527 chip remote control
5V fixed code receiving module
Working voltage: DC3.3~5V
Working frequency: 433MHz (others can be customized)
Receive sensitivity: -108dB
Output: 4-channel CMOS level signal corresponding to the ABCD 4 button of the remote control.
2272-M4 chip decoding, fixed code, suitable for PT2262/2260 remote control
Product Presentation
It can communicate with 12V four-way relay remote control switch, which can realize remote control equipment switch
12V four-way remote control switch |
|
