20ft 40ft Mobile Cabin Hospital Prefabricated Container Room Ct Examination Room
FAQ
|
Specification |
Long (mm) |
5800 |
|
Width (mm) |
2250 |
|
|
High (mm) |
2800 |
|
|
Roof form |
Flat roof, free fall |
|
|
The layer number |
Three layers or less |
|
|
Design parameter |
Years of use of structural design |
20 years |
|
Floor live load |
2.0KN/Square meter |
|
|
Roof live load |
0.5KN/Square meter |
|
|
Wind load |
0.6KN/Square meter |
|
|
Seismic fortification intensity |
8 degrees |
|
|
structure |
Angle |
Galvanized square pipe, thickness of 2.5mm, material Q235B |
|
Roof girder |
Galvanized square pipe, thickness of 2.5mm, material Q235B |
|
|
Roof second beam |
Galvanized square pipe, thickness of 2.5mm, material Q235B |
|
|
The main girder |
Galvanized square pipe, thickness of 2.5mm, material Q235B |
|
|
The ground secondary beam |
Galvanized square pipe, thickness of 2.5mm, material Q235B |
|
|
The paint |
Non-toxic and odorless environmental water-based paint, waterproof, wear-resistant, aging resistant, yellow - resistant and fast drying |
|
|
roof |
Roof panel |
Roof thickness: 0.8mm |
|
Heat preservation cotton |
Double layer 100mm thick glass fiber felt, the bulk density is greater than 14kg/m cubed, and the combustion performance is not flammable at class A |
|
|
Ceiling board |
0.5mm thick aluminum zinc plate, color white grey |
|
|
The ground |
Glass magnesium board |
15mm thick glass magnesium plate, the density is greater than 1.3 g/cm3, the combustion performance is not combustible at grade A, and the surface is added to the surface |
Q You are manufacture factory or trading company?
A:We are manufacture factory. And you are welcomed to visit us for inspection. The quality control flow will show you
ourprofessional. Also you will enjoy the best quality and competitive price.
Q:What's the quality assurance you provided and how do you control quality ?
A:Established a procedure to check products at all stages of the manufacturing process - raw materials, in process
materials, validated or tested materials, finished goods, etc. We could deal with you by Trade Assurance via .
Q:Can you offer designing service?
A:Yes, we have more than 10 design engineers. We could design full solution drawings as per your requirments. They
use software: Auto CAD,PKPM, MTS, 3D3S, Tarch, Tekla Structures(Xsteel)V12.0.etc.
Q:Do you offer guiding installation on site overseas?
A:Yes, usually we will send you the detailed installation drawing, if you need, we can provide the service of installation,
supervision and training by extra. We can send our professional technical engineer to supervise installation on
site overseas.
Q: Do you accept container loading inspection?
A: You are welcomed to send an inspector, not only for the container loading, but any time during the production time.
Q:What is the delivery time?
A: Delivery time depends on order quantities. Generally, the delivery time will be 30 days after receiving deposit.
