Modern Design Light Steel Prefab House Concrete Wall and Roof System Seismic Resistant Prefab 2 Storey House

Name: Modern Design Light Steel Prefab House Concrete Wall and Roof System Seismic Resistant Prefab 2 Storey House
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Product Descriptions

Modern Design Light Steel Prefab House Concrete Wall and Roof System Seismic Resistant Prefab 2 Storey House

• Prefab villa is based on Design & Build concept • Highly energy efficient with pre-engineered strong structural design

• Fast assembly on-site, which means lower costs for labor

• Higher health and safety quality level of the house

• Superb insulation value by the use of SIP wall panel system

Specification
Name	Light Steel Prefab House
Size	12 x 10 x 7m(H)
Shipment	one 40HC
Structure	Q235B HS Galvanised Steel
Wall	75mm EPS Sandwich Wall Panel
Wall Cladding	16mm PU Wall Cladding
Roof	75mm Rockwool Sandwich Roof Panel w/Fascia Board
Ceiling	Bamboo Composite Ceiling & Cornices
Floor	3.5mm Vinyl Wood Flooring & Skirting , 600 x 600mm Ceramic Tile (For Bathroom)
Window	5+9+5 Double glazing Aluminum Sliding Window , 1.4mm Dark Gray Aluminium Frame
Door	5+9+5 Double Glaze Sliding Door , High Grade Steel Door
Stair	High Grade Interior Steel Stair w/Wood Stepboard and Steel Railing
Kitchen	Laminated Melamine Kitchen Cabinet w/ Quartz Stone Table Top and Stainless Steel Sink
Electric	LED Lights , Switches & Sockets , 2P 63A Distribution Box
Plumbing	UPVC/PPR/PB/PERT
Color	Brown and White

Technical Data Sheet
Wind Load	Up to Grade 12 , 200kph
Seismic Load	Up to Grade 10
Snow Load	0.6KN/㎡
Live Load	0.6KN/㎡
Floor Load	145KG/㎡
Wall Impact Load	0.6KN/㎡
Wall Heat Transfer Coefficient	0.35KCAL/㎡
Sound Insolation	>45Db

Materials

Electro-Galvanised HS Steel Structures

EPS/Rockwool Sandwich Wall Panel

Lightweight Concrete Wall Panel

Powder Coated Steel Structures

Galvanised and pre-painted Trusses

Galvanised Steel Railing

High Grade Steel Door

Aluminium Window with Grille

Poly-fiber membrane vapor barrier

Packing & Delivery

Company Profile

REX CORPORATION CO,. LTD (REX Construction and Engineering Co., Ltd.)

specializes in designing, manufacturing and building of container modular house, steel structure building, prefabricated house, portable toilet & bath, guard house and kiosk. The company producing its own sandwich panels, steel structures, window and doors, and various kinds of building & decorative materials. More than 25 Years of construction, building prefabrication experiences, advanced technical knowledges and strict quality controls have put the company in the forefront as one of the most trusted firms in the industry.

Panel Production Line

We produce all kind of insulated panel ranging from EPS, Rockwool, Glass wool, PU, XPS and Phenolic as well as acoustic Supra panel.

Steel Fabrication & Quality Control

Digitalized Quality Control Management measures to all fabricated component to ensure precision of products

Fire & Anti Corrosive Treatment

Detailing of steel component before galvanisation and treatment for anti-corrosive coating

Designs & Projects

Magnificent 7 @ Taiwan

Constructed in 7 days, precision fabricated steel structure and superb workmen's skill is what it takes for this remarkable achievement in suburb of Taiwan.

Modern Touch with Big Window @ Vietnam

A fine architetural design taste for a big window allowing lights to roam into this house for a more brighter environmental living.

Modernizing Living with Prefab in Philippines

This 3 Bedrooms residence was transformed within 1 week to gives a whole new look from its traditional design.

The Elegant One @ Perth

The 4 bedrooms Prefab dwelling design and built using steel structures and PIR panel. A simple design looks elegantly in the suburb of Western Australia.

Colonial-Touch Prefab House @ Indonesia

Opting for cladding instead of the traditional painting not only provide protection for the wall but giving much better appearance and new look in this traditionally design house.

People's Housing Just Get Better @ PNG

FAST & BEAUTY for people's housing not only provide effecieny to the developers but it also provide more decent and durablity against the harsh weather in cyclone-prone area.

Environmental Friendly with Prefab @ Brazil

A Holiday Chalet built on stilt without affecting or damaging the natural surrounding and greenery.

Simple Life on Prefab

4 Workers 4 days to complete this 54 m2 hoouse with 2 bedroom in Laos.

ENQUIRIES ARE WELCOMED

Contact :Ms. Coreen Wang

Email :@gmail.com

:@gmail.com

Mob/WhatsApp :+86 15015815312

Wechat :15015815312

Skype/Line :REXCORP

Facebook :REXCORP

FAQ

1. Q: Are you a manufacturer or trading company?

A: We are more than just a manufacturer. We are also builder by trade with more than 20 years in the building and construction industry. We DESIGN, MANUFACTURE, BUILD & DELIVER to your expectation at the highest quality.

2. Q: Where are you located?
A: Our factories are located in Foshan city, Guangdong, China. Approximatly 1hour drive from Guangzhou International Airport. You may reach us via taxi direct from the airport or by train (30min) from Guangzhou Train Station or by Subway and public transports available throughout the city. You are more than welcome to visit us ANYTIME. Do let us know in advance should you need us to pick you up from the airport.

3. Q: How to get a quotation?
A: You may write to us officially requesting a quote on the specified product , quantity and provide us with your contact information. We will revert back to you within 24 hours.

4. Q: What is your payment term?
A: 50% deposit by T/T when the order is confirmed, and the balance by T/T before shipment.

5. Q: Do you provide instruction manual or video for installation?
A: We provide CUSTOMISED detailed Instruction Manuals and Video for each of our client.

6. Q: Do you provide warranty?
A: We offer warranty and a replacement scheme for all our products from damages due to poor handling or packaging by our factory's staff, subject to case-to-case basis.
