PIW-D500 Water Borehole Inspection Well Logging Camera

Main Control Box

Aluminum Alloy Main Machine

Winch

Electric Winch

Display Screen

12” High Brightness LED Monitor

Camera

Dual Camera Pan 360 degree

Depth Counter

Depth accurate to 0.05m

Well Logging Cable

Six-core Bearing Pull, Length Optional

Centralizer

High Elasticity Stainless Steel Centralizer

Main Control Box

* Aluminum Alloy Control Box

* Depth Interface: Connect the depth sensor
* Probe Interface: Connect the probe, transmit video and power
* Data Interface: Can be written into well location, well number, can be self-calibration depth
* Video System: 8G SD Card Video System, maximum 32G

* Depth Zero: Please return the depth to zero before logging, so that the counting is accurate.
* Monitor: 12” High Brightness LED Monitor, 210*310mm, Outdoor Visual, Screen resolution 1027*768

* Expansion Interface: Video Capture Expansion Interface

Winch

* Electric Winch: control the speed and probe lift by the control button of the main control box

* Downhole Pulley: Downhole pulley has the function of depth counting,but need the data line to connect the main control box to use

* Split Docking Probe: Easy to exchange the probes of different size and specification.

* Down Pulley: down pulley with depth counting function

Dual Camera Rotation Camera

* Camera Size: Φ79mm(Φ50mm wide angle camera Optional)

* Camera Material: Zinc-coated, 304 Stainless Steel optional

* Camera Window: Explosion-proof Optical Acrylic Glass Or Explosion-proof Glass Window

* Camera Pixels: CCD Camera, 1200 TVL High-definition Low-light

* Lens Angle: Side 360 degree

* Camera Light: Φ79mm dual camera, bottom camera has 6 lights, side camera has a luminous surface. Φ50mm wide angle camera, 6 or 9 lights

* Brightness Adjustment: Front and rear lamp beads, can adjust the brightness of the light source through the button in the control box, five-level dimming.

* Probe Pressure: Pressure 150bar

Pulley

* Downhole Pulley: Downhole pulley has the function of depth counting, but need the data line to connect the main control box to use

* Depth Counting Function: With Japanese Omron depth sensor, the depth display reaches millimeter

Logging Cable

* Cable Material: Custom Logging Cable

* Bearing: 260KG

* Outside Diameter: 8 mm

* Temperature Tolerance: 65 degree
