LIVTER Welding Machine Sheet Filter Screen Wire Mesh Sheet Metal Touch Welding Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
LIVTER Hss Pa20 Degree Custom Hobbing Worm Cutter Shank Type Hob
-
1800mm tile cutting machine,Fully automatic, 45 degree wood cutting machine,Multifunctional cutting machine
-
600mm Portable Stone,tile,marble manual Cutting Machine 125mm cutting depth
-
1200mm-2000mm Marble,granite,tile cutting machine,automatic tile bridge saw cutting machine
-
LIVTER tile cutting machine marble cutting manual automatic 45 degrees cutting machine 1000mm/1200mm customize
-
stone cutting machine china,stone bridge cutting machine, stone cutting machine marble granite
Product Description
Products Description
Technical data: Features of this machine: low price, low failure rate, high solder joint quality, high efficiency
Product model | rated capacity | Primary voltage | Load Continuation Rate | Welding thickness (mm) |
DN-10 | 10KVA | 380V | 20% | ≦1.5+1.5 |
DN-16 | 16KVA | 380V | 20% | ≦2+2 |
DN-25 | 25KVA | 380V | 20% | ≦3+3 |
DN-40 | 40KVA | 380V | 20% | ≦4+4 |
Model | Unit | Net basket DN-40 | DN-25 | Chicken coop DN-25 | DN-16 | DN-10 | DN-10-2 | |||||||
Technical project | ||||||||||||||
rated capacity | KVA（千伏安） | 40 | 25 | 25 | 16 | 10 | 10 | |||||||
Supply voltage | V（伏） | 380 | ||||||||||||
Primary voltage | A（安） | 105 | 65 | 65 | 42 | 26 | 26 | |||||||
Secondary voltage | V（伏） | 4.3-6.5 | 2.4-4 | 1.81-3.8 | 2-3.4 | 1.80-3.2 | 1.52-2.62 | |||||||
Regulating series | 级 | 7 | 7 | 8 | 7 | 7 | 7 | |||||||
Rated regulation series | 级 | 6 | 6 | 7 | 6 | 6 | 6 | |||||||
Number of welds per hour | 点/时 | 600-8000 | 600 | 8000 | 720 | 900 | 900 | |||||||
Welding time adjustment | S（秒） | DN series spot welding machines can be equipped with point projection welding microcomputer controller and JS time relay to precisely control welding time (1) welding time 0.02-3.98S; (2) compaction time 0.10-4.00S;(3) rest time 0.10-4.00(4) energy adjustment 10-95% | ||||||||||||
Welding thickness of low carbon steel plate | Rated | mm（毫米） | 1.5+1.5- | 1+1-3+3 | 1+1-2+2 | 0.5+0.5-2+2 | 0.3+0.3-1.5+1.5 | 0.3+0.3-1.5+1.5 | ||||||
4+4 | ||||||||||||||
Reduce the temporary load rate | mm（毫米） | 4.5+4.5 | 3.5+3.5 | 2.5+2.5 | 2.5+2.5 | 2+2 | 2+2 | |||||||
Welding Range (Diameter) of Low Carbon Steel Bar Cross Welding | mm（毫米） | 3+3-10+10 | 3+3-8+8 | 1+1-3+3 | 1+1-6+6 | 2+2-5+5 | 1.5+1.5-4+4 | |||||||
Load Continuation Rate | % | 20 | 20 | 15 | 15 | 15 | 10 | |||||||
Extension length of electrode arm | mm（毫米） | 510 | 400 | 450 | 400 | 400 | 350 | |||||||
Electrode arm spacing | mm（毫米） | 120-360 | 150 | 150 | 150 | 150 | 150 | |||||||
Upper electrode working stroke | mm（毫米） | 25 | 20 | 20 | 20 | 20 | 15 | |||||||
Cooling water consumption | kg | 200 | 450 | 400 | 400 | 350 | ||||||||
Large electrode pressure | KN | 0.8 | 1.5 | 1.5 | 1.5 | 1 | 0.7 | |||||||
Weight | kg | 245 | 165 | 165 | 140 | 130 | 63 | |||||||
Overall dimensions | mm（毫米） | 1210*380*1240 | 765*300*109 | |||||||||||
Length * width * height | 1090*365*1240 | |||||||||||||
