Help CenterElectric Heating Element for Solar Water Heater Spare Parts
Related Products
-
Outer Cover for Solar Water HeaterNegotiableMOQ: 1 -
Tank Cover of Solar Water Heater Project Tank Side DishNegotiableMOQ: 1
-
Best Seller Solar Water Heat Parts Water Tank Covers Solar Water Heater Tank Lids, Tank Side DishNegotiableMOQ: 1
-
Pure Magnesium RodNegotiableMOQ: 1
-
Solar Water Heater Accessory/Magnesium Rod/purify Water/WATER TANKNegotiableMOQ: 1
|
Specification parameter |
Detail |
Remark |
|
Sheath Material |
SUS304 |
Materialscan be changed to be copper,sus321,sus316L,incoloy804,incoloy800 as requested |
|
Voltage/wattage |
12v/200w |
Voltage/Wattage/Tolerance can be customized as required,and Wattage tolerance(cold condition)+5%-10% |
|
Tube Diameter |
8.5mm/0.33" |
Tube diameter can be customized as required |
|
Weight |
206g |
|
|
Screw thread |
1" |
Other thread can be made if required |
|
MgO |
A |
We can use other powder if requested |
|
Resistance wire |
Ocr25Al5 |
Or Ni80Cr20 |
|
Plastic shell |
Nylon |
Temperature resistance 160℃ |
|
Leads |
Stainless steel |
Materials of terminal piece could be stainless iron,stainless steel if required |
|
Faston Terminal |
Nickel plated iron |
Material of terminal housing could be stainless iron,stainless steel if required |
|
Insulation resistance |
≥1000MΩ(cold condition) |
|
|
Leak current |
≤0.5mA |
|
|
Density |
7W/cm2 |
|
|
Application |
Solar water heater |
|
|
Warranty |
1-5 years |
|
