Glass-lined Solar Water Heater Inner Tank Production Machine Enamel Coating Line for India

Shandong Zentek Energy and TechnologyCo., Ltd. , as a member of CSP Holding Group, is a professional manufacturer of production equipments and gears for both electric and solar water heaters. We have been devoting ourselves to customized design and engineering, manufacturing, machinery upgrading and production line improving for customers from all over the world.

The machineries we manufacture include fully and semi-automatic solar/electric water heater inner tank production line and outer tank production line, press machine, welding machine, foaming line and enameling line etc..

Our products have been exported to over 20 countries, such as India, Europe, Egypt, U.A.E., Mexico, Brazil etc.. Our customers include A.O. Smith and Havells in India, Artel in Uzbekistan and so on. Especially the line for Uzbekistan, it was the first complete line exported from China ever. We are looking forward to the cooperation with partners worldwide.

1.     The enamel line is used for wet enamel, drying and sintering of enamel inner tank with different specifications in bulk.  like conveying, drying, sintering will be finished on this machine automatically.

2.     Mainly used for hanging sintering. Max. size of inner tank: diameter 410mm, height: 1400mm

3.     Max. weight born by single hanger: 60Kg

4.     It is suitable for the sintering of inner tanks with different sizes and thicknesses.

5.     Heat source: natural gas. Reference: 8500kcal/m3

Please offer the actual figure.

6.     Sintering capacity: more than 1500kg per hour (hangers included ).That is more than 60 pcs/hour.

7.     Temperature control: 8 areas, 8 points

8.     Temperature ranges: 700℃~900℃; it takes less than 90 minutes for a cold furnace to reach 850℃.

1. Q: What servicesare availabe?

    A:  Services we could offer: product design, machine production, installation&debugging, local production guidance, spare parts supply etc.

2. Q: What is your payment term?

     A: 30% prepaid, 60% paid before loading, 10% paid after installation and debugging at customer's plant.

3. Q: How long will machines be delivered?

     A: The time depends on how many sets of machines you require. 20 days to 5 months.

4. Q: How will the machines be packaged?

    A:  Normally machines will be covered with film and fastened in the container. But package could be customed, like steel frame, wooden boxes etc..

5. Q: How long will the machines be guaranteed?

    A:  One year.

6. Q: How long is the lifespan of machines?

    A:  15-20 years.

7. Q: Which companies have you supplied your machines to?

    A:  Sunrain, Linuo, Sangle, Himin, Haier, A.O. Smith, Havells in India, Supreme in India, Artel in Uzbekistan etc..
